Yamaha YZF-R7 (2022) technical specifications

Yamaha YZF-R7 is produced in 2022. Engine is Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, displacement 689 cc / 42.04 cu-in , produces power 55 kW / 74.8 hp @ 8750 rpm and 68 Nm / 50 lb-ft @ 6500 rpm. Yamaha YZF-R7 wet weight is 188 kg / 414 lbs. Yamaha YZF-R7 has 10 photos.

Technical specifications

+ Add to 'Compare list'

Model:	YZF-R7
Years:	2022
Engine:	Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Capacity:	689 cc / 42.04 cu-in
Bore x Stroke:	80 x 68.6 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.5:1
Lubrication:	Wet sump
Exhaust:	Integrated 2-into-1 exhaust pipes and muffler
Induction:	Mikuni 38 mm dual bore throttle body F.I.
Emission:	Euro 5
Ignition:	TCI Transistor Controlled Ignition
Starting:	Electric
Max Power:	55 kW / 74.8 hp @ 8750 rpm
Max Power A2 License:	35 kW / 47 hp @7750 rpm
Max Torque:	68 Nm / 50 lb-ft @ 6500 rpm
Transmission:	6 Speed constant mesh
Final Drive:	Chain
Clutch:	Multiplate wet clutch, with Assist & Slipper clutch
Frame:	A high-strength steel frame with a rigid-mount aluminum center
Front Suspension:	41mm Telescopic fork, adjustable for preload, rebound and compression
Front Wheel Travel:	130 mm / 5.1 in
Rear Suspension:	Linked-type Monocross shock, adjustable preload and rebound
Rear Wheel Travel:	130 mm / 5.1 in
Front Brakes:	2x 298mm discs, 4-piston calipers
Rear Brakes:	Single 245mm disc, single piston caliper
ABS:	Standard
Front Tyre:	120/70ZR17M/C (58W) Tubeless
Rear Tyre:	180/55ZR17M/C (73W) Tubeless
Caster Angle:	23°
Trail:	90 mm
Dimensions:	Length 2070 mm / 81.5 in Width 705 mm / 27.8 in Height 1160 mm / 45.7 in
Wheelbase:	1395 mm / 54.9 in
Ground Clearance:	135 mm / 5.3 in
Seat Height:	835 mm / 32.9 in
Wet Weight:	188 kg / 414 lbs
Fuel Capacity:	13 Litres / 3.4 US gal
