Technical specifications
|
| Model: |
YZF-R 125 |
| Years: |
2015 |
|
Engine:
|
Four stroke, single cylinder, SOHC, 4 valve
|
|
Capacity:
|
124.7 cc / 7.6 cu-in
|
|
Bore x Stroke:
|
52 x 58.6 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.2:1
|
|
Induction:
|
Fuel Injection
|
|
Oil Capacity:
|
1.20 liters / 0.08 quarts)
|
|
Lubrication:
|
Wet sump
|
|
Ignition:
|
TCI
|
|
Starting:
|
Electric
|
|
Max Power:
|
11 kW / 15 hp @ 9000 rpm
|
|
Max Torque:
|
12.4 Nm / 1.25 kg-m @ 8000 rpm
|
|
Clutch:
|
Wet Multiple-disc
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Delta box
|
|
Front Suspension:
|
Upside-down telescopic fork, Ø 41 mm
|
|
Front Wheel Travel:
|
130 mm / 5.1 in
|
|
Rear Suspension:
|
Linked monoshock with spring preload adjustment
|
|
Rear Wheel Travel:
|
118 mm / 4.6 in
|
|
Front Brakes:
|
Single 292mm disc
|
|
Rear Brakes:
|
Single 230mm disc
|
|
Front Tyre:
|
110/80 -17
|
|
Rear Tyre:
|
130/70 -17
|
|
Caster:
|
26°
|
|
Trail:
|
98 mm
|
|
Dimension:
|
Height 1065 mm / 41.9 in Length 1955 mm / 76.9 in Width 680 mm / 26.7 in
|
|
Wheelbase:
|
1355 mm / 53.3 inc
|
|
Seat Height:
|
825 mm / 32.4 in
|
|
Wet Weight:
|
140 kg / 308.5 lbs
|
|
Fuel Capacity:
|
11.5 Litres / 3.0 gal
|
