Yamaha YZF 600R Thundercat (2002) technical specifications
Yamaha YZF 600R Thundercat is produced in 2002. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, displacement 599 cc / 36.5 cu-in , produces power 72.9 kW / 100 hp @ 11500 rpm and 65.7 Nm / 6.7 kgf-m / 48.7 lb-ft @ 9500 rpm. Yamaha YZF 600R Thundercat top speed is 246.8 km/h / 153.3 mph. Yamaha YZF 600R Thundercat weighs 189 kg / 417 lbs. Yamaha YZF 600R Thundercat has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | YZF 600R Thundercat |
| Years: | 2002 |
| Engine: | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder |
| Capacity: | 599 cc / 36.5 cu-in |
| Bore x Stroke: | 62 x 49.6 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 12.0:1 |
| Induction: | 4 x 36 mm Keihin CV downdraft carburetors |
| Ignition: | Digital TCI |
| Starting: | Electric |
| Max Power: | 72.9 kW / 100 hp @ 11500 rpm |
| Max Power Rear Tyre: | 67.9 kW / 91.0 hp @ 11500 rpm |
| Max Torque: | 65.7 Nm / 6.7 kgf-m / 48.7 lb-ft @ 9500 rpm |
| Transmission: | 6 Speed |
| Final Drive: | 530 O-ring chain OEM sprocket sizes per tooth Front= 15 Back= 47 |
| Frame: | Twin spar, steel, delta box |
| Front Suspension: | 41 mm telescopic fork adjustable preload, compression and rebound damping |
| Front Wheel Travel: | 130 mm / 5.1 in |
| Rear Suspension: | Monoshock adjustable preload, bump and rebound |
| Rear Wheel Travel: | 120 mm / 4.7 in |
| Front Brakes: | 2x 300 mm Discs, 4 piston calipers |
| Rear Brakes: | Single 245mm disc, 2 piston caliper |
| Front Tyre: | 120/60-17 |
| Rear Tyre: | 160/60-17 |
| Rake: | 25.0° |
| Trail: | 97 mm / 3.82 in |
| Dimensions: | Length 2060mm / 81.1 in Width 754 mm / 29.6 in Height 1190 mm / 46.8 in |
| Wheelbase: | 1415 mm / 55.7 in |
| Seat Height: | 810 mm / 31.7 in |
| Ground Clearance: | 135 mm / 5.3 in |
| Dry Weight: | 189 kg / 417 lbs |
| Wet Weight: | 210 kg / 463 lbs |
| Fuel Capacity: | 19 Litres / 5.0 US gal / 4.2 Imp gal |
| Consumption Average: | 6.1 L/100 km / 16.4 km/l / 38.6 US mpg / 46.3 Imp mpg |
| Braking 60 km/h - 0: | 13.5 m / 44.3 ft |
| Braking 100 km/h - 0: | 37.5 m / 123 ft |
| Standing ¼ Mile: | 11.3 sec / 194.7 km/h / 121 mph |
| Top Speed: | 246.8 km/h / 153.3 mph |
