Technical specifications
|
Model: |
YZF 600 R6 |
Years: |
2009 |
Engine:
|
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
|
Capacity:
|
599 cc / 36.5 cu-in
|
Bore x Stroke:
|
67 x 42.5 mm
|
Compression Ratio:
|
13.1;1
|
Cooling System:
|
Liquid cooled
|
Lubrication:
|
Wet sump
|
Oil Capacity:
|
3.4 Litres
|
Engine Oil:
|
10W/30
|
Induction:
|
41 mm Mikuni throttle body F.I.
|
Ignition:
|
TCI
|
Spark Plug:
|
NGK, CR10EK
|
Starting:
|
Electric
|
Max Power:
|
94.9 kW / 129 hp @ 14500 rpm
|
Max Power Ram Air:
|
99.6 kW / 135 hp @ 14500 rpm
|
Max Torque:
|
65.8 Nm / 6.71 kgf-m @ 11000 rpm
|
Max Torque Ram Air:
|
69.1 Nm / 7.05 kgf-m @ 11000 rpm
|
Clutch:
|
Wet, slipper, cable operated
|
Transmission:
|
6 Speed
|
Final Drive:
|
O-ring chain
|
Gear Ratio:
|
1st 31/12 (2.583) / 2nd 32/16 (2.000) / 3rd 30/18 (1.667) / 4th 26/18 (1.444) / 5th 27/21 (1.286) / 6th 23/20 (1.150)
|
Frame:
|
Deltabox aluminium frame with revised rigidity balance
|
Front Suspension:
|
Fully adjustable 41 mm inverted cartridge fork,
|
Front Wheel Travel:
|
119.4 mm / 4.7 in
|
Rear Suspension:
|
Fully adjustable link Monocross; 4-way adjustable,
|
Rear Wheel Travel:
|
119.4 mm / 4.7 in
|
Front Brakes:
|
2x 310mm discs 4 piston calipers
|
Rear Brakes:
|
Single 220mm disc 1 piston caliper
|
Front Tyre:
|
120/70 ZR17
|
Rear Tyre:
|
180/55 ZR17
|
Dimensions:
|
Length 2040mm / 80.3in Width 705mm / 27.8'in Height 1095mm / 43.1in
|
Wheelbase:
|
1375 mm / 54.1 in
|
Rake:
|
24°
|
Trail:
|
97mm / 3.8 in
|
Ground Clearance:
|
130 mm / 5.1 in
|
Seat Height:
|
850 mm / 33.5 in
|
Dry Weight:
|
166 kg / 366 lbs
|
Wet Weight:
|
188 kg / 413.6 lb
|
Fuel Capacity:
|
17.5 Liters / 3.7 gal
|
Consumption Average:
|
19.3 km/lit
|
Standing ¼ Mile:
|
11.6 sec
|
Top Speed:
|
256.9 km/h
|
