Yamaha YZF 1000 R1M (2016) technical specifications

Yamaha YZF 1000 R1M is produced in 2016. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 998 cc / 60.9 cu-in , produces power 147.1 kW / 200.0 hp @ 13500 rpm and 112.4 Nm / 11.5 kg-m @ 11500 rpm. Yamaha YZF 1000 R1M wet weight is 199 kg / 439 lbs. Yamaha YZF 1000 R1M has 9 photos.

Technical specifications

+ Add to 'Compare list'

Model:	YZF 1000 R1M
Years:	2016
Engine:	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Capacity:	998 cc / 60.9 cu-in
Bore x Stroke:	79.0 x 50.9 mm
Compression Ratio:	13.0:1
Cooling System:	Liquid cooled
Lubrication:	Wet sump
Engine Management:	YCC-T, YCC-I, PWR, TCS, LCS, LIF, SCS, QSS, CCU & SCU
Induction:	Fuel Injection with YCC-T and YCC-I
Ignition:	TCI: Transistor Controlled Ignition
Starting:	Electric
Max Power:	147.1 kW / 200.0 hp @ 13500 rpm
Max Torque:	112.4 Nm / 11.5 kg-m @ 11500 rpm
Clutch:	Wet, Multiple Disc
Transmission:	6-speed w/multiplate slipper clutch
Final Drive:	"O" ring chain
Front Suspension:	43mm KYB® inverted fork; fully adjustable
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	KYB® Single shock w/piggyback reservoir, 4-way adjustable
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2x 320mm discs 4 piston calipers, UBS ABS
Rear Brakes:	Single 220mm disc 1 piston caliper, UBS ABS
Front Tyre:	120/70 ZR17
Rear Tyre:	190/55 ZR17
Dimensions:	Length 2054.8 mm / 80.9 in Width 690 mm / 27.2 in Height 1150 mm / 45.3 in
Wheelbase:	1419 mm / 55.9 in
Ground Clearance:	135mm / 5.3 in
Seat Height:	830 mm / 32.7 in
Wet Weight:	199 kg / 439 lbs
Fuel Capacity:	17 Liters / 4.5 US gal
