Yamaha YZF 1000 R1 (2009) technical specifications

Yamaha YZF 1000 R1 is produced in 2009. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 998 cc / 60.9 cu-in , produces power 133.9 kW / 182 hp @ 12500 rpm and 115.5 Nm / 11.8 kgf-m @ 10000 rpm. Yamaha YZF 1000 R1 top speed is 280.9 km/h. Yamaha YZF 1000 R1 weighs 177 kg / 389.4 lb. Yamaha YZF 1000 R1 has 10 photos.

Technical specifications

+ Add to 'Compare list'

Model:	YZF 1000 R1
Years:	2009
Engine:	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Capacity:	998 cc / 60.9 cu-in
Bore x Stroke:	78 X 52.2 mm
Compression Ratio:	12.8:1
Cooling System:	Liquid cooled
Engine Oil:	Synthetic, 10W/40
Lubrication:	Wet sump
Induction:	Mikuni 45mm throttle body FI
Ignition:	TCI: Transistor Controlled Ignition
Spark Plug:	NGK, CR9EK
Starting:	Electric
Max Power:	133.9 kW / 182 hp @ 12500 rpm
Max Torque:	115.5 Nm / 11.8 kgf-m @ 10000 rpm
Clutch:	Cable-operated multiplate wet slipper clutch.
Transmission:	6 Speed
Final Drive:	"O" ring chain
Gear Ratio:	1st 38/15 (2.533) 2nd 33/16 (2.063) 3rd 37/21 (1.762) 4th 35/23 (1.522) 5th 30/22 (1.364) 6th 33/26 (1.269)
Frame:	Deltabox V aluminium
Front Suspension:	43mm inverted telescopic fork w/adjustable preload, compression damping, rebound damping;
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Single shock w/piggyback reservoir; adjustable for hi-/lo-speed compression damping, rebound damping, spring preload,
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2x 310mm discs 6 piston calipers
Rear Brakes:	Single 220mm disc 1 piston caliper
Front Tyre:	120/70 ZR17
Rear Tyre:	190/55 ZR17
Rake:	24°
Trail:	102 mm / 4.0 in
Dimensions:	Length 2070 mm / 81.5 in Width 715 mm / 28.1 in Height 1130 mm / 44.5 in
Wheelbase:	1415 mm / 55.7 in
Ground Clearance:	135mm / 5.3 in
Seat Height:	835 mm / 32.8 in
Dry Weight:	177 kg / 389.4 lb
Wet Weight:	206 kg / 454 lb
Fuel Capacity:	18 Litres / 4.8 gal
Standing ¼ Mile:	10.5 sec
Top Speed:	280.9 km/h
