Technical specifications
|
| Model: |
XTZ 250 Lander X |
| Years: |
2009 |
|
Engine:
|
Four stroke, single cylinder. SOHC, 2 valve
|
|
Capacity:
|
249 cc / 15.2 cu-in
|
|
Bore x Stroke:
|
74.0 x 58.0mm
|
|
Cooling System:
|
Air /oil cooled
|
|
Compression Ratio:
|
9.5: 1
|
|
Induction:
|
Injection
|
|
Ignition:
|
TCI
|
|
Starting:
|
Electric
|
|
Max Power:
|
21 hp / 15.3 kW @ 7500 rpm
|
|
Max Torque:
|
21 Nm / 2.09 kgf-m @ 6500 rpm
|
|
Clutch:
|
Wet plate
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Semi-double cradle frame
|
|
Front Suspension:
|
35mm telescopic fork
|
|
Front Wheel Travel:
|
240 mm / 9.4 in
|
|
Rear Suspension:
|
Swingarm w/rebound-adjustable single shock
|
|
Rear Wheel Travel:
|
220 mm / 8.7 in
|
|
Front Brakes:
|
Single 245mm disc
|
|
Rear Brakes:
|
Single 203mm disc
|
|
Front Tyre:
|
110/70-17
|
|
Rear Tyre:
|
130/70 -17
|
|
Rake:
|
24.5°
|
|
Trail:
|
72 mm / 2.8 in
|
|
Wheelbase:
|
1365 mm / 53.7 in
|
|
Seat Height:
|
870 mm / 34.2 in
|
|
Dry Weight:
|
124 kg / 275 lbs
|
|
Wet Weight:
|
133 kg / 293.3lbs
|
|
Fuel Capacity:
|
11 Litres / 2.9 US gal
|
