Yamaha XT660R (2004) technical specifications

Yamaha XT660R is produced in 2004. Engine is Four stroke, single cylinder, SOHC, 4 valve, displacement 659 cc/ 40.2 cu-in , produces power 33.8 kW / 48 hp @ 6000 rpm and 58.4 Nm / 5.7 kgf-m @ 5250 rpm. Yamaha XT660R top speed is 164.7 km/h / 102.3 mph. Yamaha XT660R wet weight is 181 kg / 421 lbs. Yamaha XT660R has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	XT660R
Years:	2004
Engine:	Four stroke, single cylinder, SOHC, 4 valve
Capacity:	659 cc/ 40.2 cu-in
Bore x Stroke:	100 x 84 mm
Compression Ratio:	10.0: 1
Cooling System:	Liquid cooled
Induction:	Fuel injection, 44 mm throttle body
Lubrication:	Dry sump
Oil Capacity:	2.9 Litres / 0.19 quarts
Ignition:	TCI
Starting:	Electric
Max Power:	33.8 kW / 48 hp @ 6000 rpm
Max Torque:	58.4 Nm / 5.7 kgf-m @ 5250 rpm
Clutch:	Wet, multiple-disc coil spring
Transmission:	5 Speed
Final Drive:	Chain
Frame:	Steel tubular diamond frame with dual tank rails
Front Suspension:	43 mm Telescopic forks,
Front Wheel Travel:	225 mm / 8.8 in
Rear Suspension:	Oscillating arm standard Monocross. 200mm wheel travel
Rear Wheel Travel:	200 mm / 7.9 in
Front Brakes:	Single 298mm disc 2 piston caliper
Rear Brakes:	Single 245mm disc 1 piston caliper
Front Tyre:	90/90- 21
Rear Tyre:	130/80–17
Rake:	27.0°
Trail:	107 mm / 4.2 in
Dimensions:	Height 1230 mm / 48.4 in Length 2240 mm / 88.1 in Width 845 mm / 33.2 in
Wheelbase:	1505 mm / 59.3 in
Ground Clearance:	210 mm / 8.3 in
Seat Height:	865mm / 34.1 in
Dry Wight:	172 kg / 379.2 lbs
Wet Weight:	181 kg / 421 lbs
Fuel Capacity:	15 Litres / 3.3 US gal
Consumption Average:	23 km/lit
Standing ¼ Mile:	14.2 sec
Top Speed:	164.7 km/h / 102.3 mph
