Technical specifications
|
| Model: |
XT 225 Serow |
| Years: |
1990-93 |
|
Engine:
|
Four stroke, single cylinder, SOHC, 2 valve
|
|
Capacity:
|
223 cc / 13.6 cu-in
|
|
Bore x Stroke:
|
70 X 58mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
9.5:1
|
|
Induction:
|
34mm Mikuni carburetor
|
|
Ignition:
|
CDI
|
|
Starting:
|
Electric & Kick
|
|
Max Power:
|
20 hp / 15 kW @ 8000 rpm
|
|
Max Torque:
|
19 Nm / 14 lb-ft @ 7000 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
Telescopic fork
|
|
Front Wheel Travel:
|
226 mm / 8.9 in
|
|
Rear Suspension:
|
Swingarm rebound adjustable. single shock
|
|
Rear Wheel Travel:
|
145 mm / 5.7 in
|
|
Front Brakes:
|
Single 220mm disc
|
|
Rear Brakes:
|
Single disc
|
|
Front Tyre:
|
2.75-21
|
|
Rear Tyre:
|
120/80-18
|
|
Dimensions:
|
Height 1161 mm / 45.7 in Length 2070 mm / 81.5 in Width 805 mm / 31.7 in
|
|
Wheelbase:
|
1349 mm / 53.1 in
|
|
Seat Height:
|
810 mm / 31.9 in
|
|
Ground Clearance:
|
285 mm / 11.2 in
|
|
Dry Weight:
|
108 kg / 238 lbs
|
|
Fuel Capacity:
|
8.7 Liters / 2.3 US gal
|
