Yamaha XS 650 / TX 650 (1980-81) technical specifications
Yamaha XS 650 / TX 650 is produced in 1980-81. Engine is Four stroke, parallel twin cylinder, SOHC, 2 valves per cylinder., displacement 653 cc / 39.8 cu in , produces power 39.5 kW / 53 hp @ 7200 rpm and 54 Nm / 5.5 kgf-m / 39.8 lb-ft @ 6800 rpm. Yamaha XS 650 / TX 650 top speed is 185 km/h / 115 mph. Yamaha XS 650 / TX 650 weighs 191 kg / 420 lbs. Yamaha XS 650 / TX 650 has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | XS 650 / TX 650 |
| Years: | 1980-81 |
| Engine: | Four stroke, parallel twin cylinder, SOHC, 2 valves per cylinder. |
| Capacity: | 653 cc / 39.8 cu in |
| Bore x Stroke: | 75 x 74 mm |
| Compression Ratio: | 8.4:1 |
| Cooling System: | Air cooled |
| Lubrication: | Wet sump |
| Induction: | 2 x Mikuni BS34 carburetors |
| Ignition: | Battery, induction coil |
| Starting: | Electric and kick |
| Max Power: | 39.5 kW / 53 hp @ 7200 rpm |
| Max Torque: | 54 Nm / 5.5 kgf-m / 39.8 lb-ft @ 6800 rpm |
| Transmission: | 5 Speed |
| Final Drive: | Chain |
| Front Suspension: | Telescopic forks |
| Rear Suspension: | Dual shock absorbers |
| Front Brakes: | Twin hydraulic discs, 267 mm |
| Rear Brakes: | Drum |
| Front Tyre: | 3.50H-19 4PR |
| Rear Tyre: | 4.00H-18 4PR |
| Dimensions: | Length: 2175 mm / 85.6" Width: 780 mm / 30.7" Height: 1090 mm / 42.9" |
| Wheelbase: | 1435 mm / 56.5" |
| Ground Clearance: | 150 mm / 5.5" |
| Seat Height: | 810 mm / 31.9" |
| Dry Weight: | 191 kg / 420 lbs |
| Wet Weight: | 217 kg / 478 lbs |
| Fuel Capacity: | 15 Litres / 4.0 US gal |
| Average Consumption: | 5.0 L/100 km / 20 km/l / 47 US mpg |
| Oil Capacity: | 2.5 Litres / 2.6 US qts |
| Top Speed: | 185 km/h / 115 mph |
