Yamaha XMAX 125 (2014-15) technical specifications

Yamaha XMAX 125 is produced in 2014-15. Engine is Four stroke, single cylinder, displacement 124 cc / 7.6 cu-in , produces power 13.8 hp / 10.1 kW @ 8750 rpm and 11.33 Nm / 8.4 lb-ft @ 6500 rpm. Yamaha XMAX 125 weighs 153 kg / 337.3 lbs. Yamaha XMAX 125 has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	XMAX 125
Years:	2014-15
Engine:	Four stroke, single cylinder
Capacity:	124 cc / 7.6 cu-in
Bore x Stroke:	52 x 58.6 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.2:1
Lubrication:	Wet sump
Induction:	Fuel Injection
Ignition:	Electronic ECU
Starting:	Electric
Max Power:	13.8 hp / 10.1 kW @ 8750 rpm
Max Torque:	11.33 Nm / 8.4 lb-ft @ 6500 rpm
Transmission:	Automatic
Final Drive:	Belt
Front Suspension:	Hydraulic telescopic fork
Rear Suspension:	Hydraulic unit swing
Front Brakes:	Single 267mm disc
Rear Brakes:	Single 240mm disc
Front Tyre:	120/70-M15
Rear Tyre:	140/70-M14
Dimensions:	Height 1385 mm / 54.5 in Width 790 mm / 31.1 in Length 2210 mm / 87.0 in
Wheelbase:	1545 mm / 60.8 in
Seat Height:	785 mm / 30.9 in
Ground Clearance:	113 mm / 4.4 in
Dry Weight:	153 kg / 337.3 lbs
Fuel Capacity:	12.5 Litres / 3.3 gal
