Yamaha XMAX 125 (2006-08) technical specifications
Yamaha XMAX 125 is produced in 2006-08. Engine is Four stroke, single cylinder, displacement 124 cc / 7.6 cu-in , produces power 13.8 hp / 10.1 kW @ 8750 rpm and 11.33 Nm / 8.4 lb-ft @ 6500 rpm. Yamaha XMAX 125 weighs 153 kg / 337.3 lbs. Yamaha XMAX 125 has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | XMAX 125 |
| Years: | 2006-08 |
| Engine: | Four stroke, single cylinder |
| Capacity: | 124 cc / 7.6 cu-in |
| Bore x Stroke: | 52 x 58.6 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 11.2:1 |
| Lubrication: | Wet sump |
| Induction: | Fuel Injection |
| Ignition: | Electronic ECU |
| Starting: | Electric |
| Max Power: | 13.8 hp / 10.1 kW @ 8750 rpm |
| Max Torque: | 11.33 Nm / 8.4 lb-ft @ 6500 rpm |
| Transmission: | Automatic |
| Final Drive: | Belt |
| Front Suspension: | Hydraulic telescopic fork |
| Rear Suspension: | Hydraulic unit swing |
| Front Brakes: | Single 267mm disc |
| Rear Brakes: | Single 240mm disc |
| Front Tyre: | 120/70-M15 |
| Rear Tyre: | 140/70-M14 |
| Dimensions: | Height 1385 mm / 54.5 in Width 790 mm / 31.1 in Length 2210 mm / 87.0 in |
| Wheelbase: | 1545 mm / 60.8 in |
| Seat Height: | 785 mm / 30.9 in |
| Ground Clearance: | 113 mm / 4.4 in |
| Dry Weight: | 153 kg / 337.3 lbs |
| Fuel Capacity: | 12.5 Litres / 3.3 gal |
