Technical specifications
|
| Model: |
XJ 700X Maxim |
| Years: |
1985 |
|
Engine:
|
Four stroke, transverse four cylinder, DOHC, 5 valves per cylinder
|
|
Capacity:
|
697.3 cc / 42.5 cu-in
|
|
Bore x Stroke:
|
68.0 x 48.0 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.2:1
|
|
Induction:
|
4x Standard side-draft 33 mm Mikuni CV
|
|
Ignition:
|
Hitachi TID14-35 TCI
|
|
Starting:
|
Electric
|
|
Max Power:
|
64.1 kW / 86 hp @ 9500 rpm
|
|
Max Torque:
|
67.6 Nm / 49.9 ft-lb @ 8000 rpm
|
|
Clutch:
|
Wet/multi-disc
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Shaft
|
|
Gear Ratio:
|
1st 35/16 (2.187) 2nd 30/20 (1.500) 3rd 30/26 (1.153) 4th 28/30 (0.933) 5th 26/32 (0.812)
|
|
Frame:
|
Double Cradle
|
|
Front Suspension:
|
38mm Telescopic fork, air, coil spring, oil damper
|
|
Front Wheel Travel:
|
150 mm / 5.9 in cast aluminum 5-spoke
|
|
Rear Suspension:
|
Swing arm Coil spring, oil damper
|
|
Rear Wheel Travel:
|
99 mm / 3.9 in cast aluminum hoop
|
|
Front Brakes:
|
2x discs 4 piston caliper
|
|
Rear Brakes:
|
Drum
|
|
Front Tyre:
|
100/90-19 57H ( 90 mm depth)
|
|
Rear Tyre:
|
130/90-16 67H (117 mm depth)
|
|
Rake:
|
31.5°
|
|
Trail:
|
120 mm / 4.7 in
|
|
Dimensions:
|
Length 2235 mm / 88.0 in Width 775 mm / 30.5 in Height 1160 mm / 45.7 in
|
|
Wheelbase:
|
1520 mm / 59.8 in
|
|
Seat Height:
|
760 mm / 29.9 in
|
|
Ground Clearance:
|
145 mm / 5.7 in
|
|
Dry Weight:
|
215 kg / 474 lbs
|
|
Wet Weight:
|
232 kg / 511 lbs
|
|
Fuel Capacity:
|
13 Litres / 3.43 US Gal
|
|
