Technical specifications
|
| Model: |
WR450F |
| Years: |
2011-12 |
|
Engine:
|
Four stroke, Single cylinder, DOHC, 5 valves
|
|
Capacity:
|
449 cc / 27.4 cu in
|
|
Bore x Stroke:
|
95 x 63.4 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
12.3:1
|
|
Lubrication:
|
Dry sump
|
|
Oil Capacity:
|
1.2 L / 2.5 US pt
|
|
Exhaust:
|
Single, upswept, under seat
|
|
Induction:
|
39mm Keihin FCR flat-slide throttle position sensor
|
|
Ignition:
|
CDI
|
|
Starting:
|
Electric & kick
|
|
Max Power:
|
58 hp / 42.3 kW @ 9000 rpm
|
|
Max Torque:
|
5.0 kgf-m 36.2 ft-lb @ 7500 rpm
|
|
Clutch:
|
Wet, multi-disc
|
|
Transmission:
|
5-Speed, constant mesh
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Aluminium bilateral beam
|
|
Front Suspension:
|
48mm Upside down telescopic fork
|
|
Front Wheel Travel:
|
300 mm / 11.8 in
|
|
Rear Suspension:
|
Swingarm, link suspension, mono shock
|
|
Rear Wheel Travel:
|
305 mm / 12.0 in
|
|
Front Brakes:
|
Hydraulic single 250 mm disc 4 piston caliper
|
|
Rear Brakes:
|
Single 245 mm disc 2 piston caliper
|
|
Wheels:
|
Aluminium alloy, laced spokes
|
|
Front Tyre:
|
80/100-21 51P
|
|
Rear Tyre:
|
120/90-18 65P
|
|
Rake:
|
27°
|
|
Trail:
|
115 mm / 4.5 in
|
|
Dimensions:
|
Length: 2315 mm / 91.1 in Width: 825 mm / 32.5 in Height: 1275 mm / 50.2 in
|
|
Wheelbase:
|
1475 mm / 58.1 in
|
|
Ground Clearance:
|
335 mm / 13.2 in
|
|
Seat Height:
|
960 mm / 37.8 in
|
|
Dry Weight:
|
112.5 kg / 268 lbs
|
|
Wet Weight:
|
122 kg / 268 lbs
|
|
Fuel Capacity:
|
7.2 Litres / 1.9 US gal
|
