Technical specifications
|
| Model: |
V-Max |
| Years: |
1993-94 |
|
Engine:
|
Four stroke, V-four, DOHC, 4 valve per cylinder.
|
|
Capacity:
|
1198 cc / 73.1 cu-in
|
|
Bore x Stroke:
|
76 х 66 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
10.5:1
|
|
Induction:
|
4x 35mm Mikuni BDS35 carburetor
|
|
Ignition:
|
CDI
|
|
Starting:
|
Electric
|
|
Max Power:
|
102 hp / 74.4 kW @ 8000 rpm
|
|
Max Power Rear Tyre:
|
97.88 @ 7700 rpm
|
|
Max Torque:
|
114.7 Nm / 86.4 lb-ft @ 6000 rpm
|
|
Clutch:
|
Wet, multi disc
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Shaft
|
|
Frame:
|
Double cradle steel tube
|
|
Front Suspension:
|
40mm Kayaba forks, Air pressure
|
|
Front Wheel Travel:
|
140 mm / 5.5 in
|
|
Rear Suspension:
|
Dual Kayaba shocks, adjustable for preload damping.
|
|
Rear Wheel Travel:
|
100 mm / 3.9in
|
|
Front Brakes:
|
2x 298mm discs 2 piston calipers
|
|
Rear Brakes:
|
Single 282mm disc 2 piston caliper
|
|
Front Tyre:
|
110/90-18
|
|
Rear Tyre:
|
150/90-15
|
|
Rake:
|
29°
|
|
Trail:
|
119 mm / 4.7 in
|
|
Wheelbase:
|
1590 mm / 65.6 in
|
|
Seat height:
|
765 mm / 30.1 in
|
|
Ground Clearance:
|
145 mm / 5.7 in
|
|
Dry Weight:
|
262 kg / 577.6 lbs
|
|
Fuel Capacity:
|
15 Litres / 3.9 US gal
|
|
Consumption Average:
|
13.1 km/lit
|
|
Braking 60 - 0 / 100 - 0:
|
13.2 m / 39.0 m
|
|
Standing ¼ Mile:
|
11.7 sec / 185.8 km/h
|
|
Top Speed:
|
216.7 km/h
|
