Yamaha TX 750 (1973) technical specifications
Yamaha TX 750 is produced in 1973. Engine is Four stroke, parallel twin cylinders, SOHC 2 valve per cylinder, displacement 743 cc / 45.3 cu-in , produces power 63 hp / 45.9 kW @ 6100 rpm and 7 kgf-m / 50.6 lb-ft @ 6000 rpm. Yamaha TX 750 wet weight is 235 kg / 518 lbs. Yamaha TX 750 has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | TX 750 |
| Years: | 1973 |
| Engine: | Four stroke, parallel twin cylinders, SOHC 2 valve per cylinder |
| Capacity: | 743 cc / 45.3 cu-in |
| Bore x Stroke: | 80 x 74 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 8.8:1 |
| Lubrication: | Forced dry sump |
| Induction: | Carburetor |
| Ignition: | |
| Starting: | Electric & Kick |
| Max Power: | 63 hp / 45.9 kW @ 6100 rpm |
| Max Torque: | 7 kgf-m / 50.6 lb-ft @ 6000 rpm |
| Transmission: | 5 Speed |
| Final Drive: | Chain |
| Front Suspension: | Telescopic forks |
| Rear Suspension: | Dual shock |
| Front Brakes: | Single or dual 300mm disc 2 piston calipers (In Japan, the United States, and other markets the bike had a single disc, although the lugs needed to mount a second disc were in place. ) |
| Rear Brakes: | 180mm Drum |
| Front Tyre: | 3.50-19 |
| Rear Tyre: | 4.00-18 |
| Rake: | 27° |
| Trail: | 99 mm / 3.9 in |
| Dimensions: | Length 2205 mm / 86.8 in Width 909 mm / 35.8 in Height 1165 mm / 45.9 in |
| Wheelbase: | 1455 mm / 57.3 in |
| Seat Height: | 810 mm / 32 in |
| Ground Clearance: | 160 mm / 6.3 in |
| Wet Weight: | 235 kg / 518 lbs |
| Fuel Capacity: | 14 Litres / 3.7 US gal |
