Yamaha TW 225E (2002-04) technical specifications
Yamaha TW 225E is produced in 2002-04. Engine is Four stroke, single cylinder, SOHC, 2-valve, displacement 223 , produces power NA and NA. Yamaha TW 225E weighs 120 kg. Yamaha TW 225E has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | TW 225E |
| Years: | 2002-04 |
| Engine: | Four stroke, single cylinder, SOHC, 2-valve |
| Capacity: | 223 |
| Bore x Stroke: | 70 X 58mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.5:1 |
| Induction: | 34mm Mikuni |
| Ignition: | CDI |
| Max Power: | NA |
| Max Torque: | NA |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Front Suspension: | Telescopic fork: 226mm wheel travel |
| Rear Suspension: | Swingarm rebound adjustable. single shock, 145mm.wheel travel |
| Front Brakes: | Single 220mm disc |
| Rear Brakes: | 110mm drum |
| Front Tyre: | 130/80-18 |
| Rear Tyre: | 180/80-14 |
| Dry Weight: | 120 kg |
| Fuel Capacity: | 7 Litres |
