Yamaha TMAX 530DX (2017-18) technical specifications

Yamaha TMAX 530DX is produced in 2017-18. Engine is Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder., displacement 530 cc / 32.34 cu-in , produces power 45.3 hp / 33.8 kW @ 6750 rpm and 52.3 Nm / 38.6 ft.lbs @ 5250 rpm. Yamaha TMAX 530DX wet weight is 216 kg / 476 lbs. Yamaha TMAX 530DX has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	TMAX 530DX
Years:	2017-18
Engine:	Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder.
Capacity:	530 cc / 32.34 cu-in
Bore x Stroke:	68.0 x 73.0 mm
Cooling System:	Liquid cooled
Compression Ratio:	10:9 : 1
Lubrication:	Semi-dry-sump
Induction:	Injection. Electronic fuel injection
Ignition:	TCI
Starting:	Electric
Max Power:	45.3 hp / 33.8 kW @ 6750 rpm
Max Torque:	52.3 Nm / 38.6 ft.lbs @ 5250 rpm
Clutch:	Wet, multiple-disc automatic
Transmission:	Fully automatic CVT
Final Drive:	V-Belt
Front Suspension:	43mm Telescopic forks
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Swingarm - single shock
Rear Wheel Travel:	116 mm / 4.6 in
Front Brakes:	2x 267 discs
Rear Brakes:	Single 267 disc
Front Tyre:	120/70-15
Rear Tyre:	160/60-15
Dimensions:	Length 2200mm / 86.6 in Width 765mm / 30.1 in Height 1420 or 1555mm / 55.9 or 61.2 in
Wheelbase:	1575 mm / 62.0 in
Seat Height:	800 mm / 31.5 in
Ground Clearance:	125mm / 4.9 in
Wet Weight:	216 kg / 476 lbs
Fuel Capacity:	15 Litters / 4 gal
