Technical specifications
|
| Model: |
MT-03 |
| Years: |
2008-09 |
|
Engine:
|
Four stroke, single cylinder, 4 valve
|
|
Capacity:
|
659 cc / 40.2 cu-in
|
|
Bore x Stroke:
|
100 x 84 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
10.0: 1
|
|
Induction:
|
Fuel injection, 44 mm throttle body
|
|
Ignition:
|
TCI
|
|
Starting:
|
Electric
|
|
Max Power:
|
33.8 kW / 48 hp @ 6000 rpm
|
|
Max Torque:
|
58.4 Nm 5.7 kgf-m @ 5250 rpm
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Steel tube truss diamond
|
|
Front Suspension:
|
Telescopic forks
|
|
Front Wheel Travel:
|
130 mm / 5.1 in
|
|
Rear Suspension:
|
Swinging arm
|
|
Rear Wheel Travel:
|
122 mm / 4.75 in
|
|
Front Brakes:
|
2x 295mm discs
|
|
Rear Brakes:
|
Single 245mm disc
|
|
Front Tyre:
|
120/70 -17
|
|
Rear Tyre:
|
160/60 -17
|
|
Dimensions:
|
Height 1115 mm / 43.9 in Length 2070 mm / 81.5 in Width 860 mm / 33.9 in
|
|
Wheelbase:
|
1420 mm / 55.9 in
|
|
Seat height:
|
805 mm / 31.7 in
|
|
Ground Clearance:
|
200 mm / 7.9 in
|
|
Dry Weight:
|
174.5 kg / 384.7 lbs
|
|
Fuel Capacity:
|
15 Litres / 3.9 US gal
|
|
Standing ¼ Mile:
|
14.2 sec
|
|
Top Speed:
|
163.3 km/h
|
