Yamaha FZR 1000 Genesis (1988) technical specifications
Yamaha FZR 1000 Genesis is produced in 1988. Engine is Four stroke, 35° forward inclined transverse four cylinder, DOHC, 5 valves per cylinder, displacement 989 cc / 60.9 cu-in , produces power 135 hp / 100.8 kW @ 10000 rpm and 10.4 kgf-m / 102 Nm @ 8500 rpm. Yamaha FZR 1000 Genesis top speed is 256.6 km/h / 159.4 mph. Yamaha FZR 1000 Genesis weighs 204 kg / 449.7 lbs. Yamaha FZR 1000 Genesis has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | FZR 1000 Genesis |
| Years: | 1988 |
| Engine: | Four stroke, 35° forward inclined transverse four cylinder, DOHC, 5 valves per cylinder |
| Capacity: | 989 cc / 60.9 cu-in |
| Bore x Stroke: | 75 x 56 mm |
| Cooling System: | Liquid cooled |
| Oil Pump Type: | Double-rotor trochoid |
| Oil Capacity: | 3.7 Litres |
| Compression Ratio: | 11.2:1 |
| Induction: | 4x 37mm BDS Mikuni carburetors |
| Ignition: | Digital Transistor Controlled Ignition (Digital T.C.I.) |
| Generator: | A.C. Generator Battery 12V i4Ah |
| Starting: | Electric |
| Max Power: | 135 hp / 100.8 kW @ 10000 rpm |
| Max Torque: | 10.4 kgf-m / 102 Nm @ 8500 rpm |
| Clutch: | Wet, multiplate disc, hydraulic |
| Transmission: | 5 Speed |
| Final Drive: | Chain, 532 'O'-ring type |
| Primary Reduction Ratio: | 68/41 (1.659) |
| Secondary Reduction Ratio: | 46/16 (2.875) |
| Gear Ratio: | 1st 36/14(2.571) 2nd 32/18(1.778) 3rd 29/21 (1.381) 4th . 27/23(1.174) 5th 28/27(1.037) |
| Frame: | Double cradle aluminium DELTABOX |
| Front Suspension: | 41mm Telescopic infinite preload adjustable. |
| Front Wheel Travel: | 130 mm / 5.1 in |
| Rear Suspension: | Monoshock infinite preload adjust |
| Rear Wheel Travel: | 130 mm / 5.1 in |
| Front Brakes: | 2x 317 mm discs 4 piston calipers |
| Rear Brakes: | Single 264 mm disc 2 piston caliper |
| Rim Front: | MT 3.50 x 17 (cast aluminium) |
| Rim Rear: | MT 4.50 x 18 (cast aluminium) |
| Front Tyre: | 120/70 VR17 |
| Rear Tyre: | 160/60 VR18 |
| Steering Head Bearing Type: | Taper roller |
| Rake: | 24.6° |
| Trail: | 98 mm / 3.8 in |
| Dimensions: | Length 2210 mm / 87.0 in Width 730 mm / 28.7 in Height 1220 mm / 48.0 in |
| Wheelbase: | 1470 mm / 57.8 in |
| Seat Height: | 150 mm / 5.8 in |
| Ground Clearance: | 790 mm / 31.1 in |
| Dry Weight: | 204 kg / 449.7 lbs |
| Wet Weight: | 225 kg / 496 lbs |
| Fuel Capacity: | 20 Litres / 4.5 gal |
| Reserve: | 4.5 Litres / 1.02 gal |
| Consumption Average: | 15.8 km/lit |
| Braking 60 - 0 / 100 - 0: | 13.1 m / 37.6 m |
| Standing ¼ Mile: | 10.7 sec / 204.97 km/h |
| Top Speed: | 256.6 km/h / 159.4 mph |
| Road Test: | Moto Sprint 1987 Group Test |
