Technical specifications
|
| Model: |
FZ6R |
| Years: |
2009 |
|
Engine:
|
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
|
|
Capacity:
|
599 cc / 36.5 cu-in
|
|
Bore x Stroke:
|
65.5 x 44.5 mm
|
|
Compression Ratio:
|
12.2:1
|
|
Cooling System:
|
Liquid cooled
|
|
Lubrication:
|
Wet sump
|
|
Induction:
|
Group injection type fuel injection
|
|
Ignition:
|
Digital TCI
|
|
Starting:
|
Electric
|
|
Clutch:
|
Wet Multi-plat disc
|
|
Max Power:
|
77.5 hp / 57 kW @ 11500 rpm
|
|
Max Torque:
|
51.6 Nm / 6.1 kg-m / 44.1 ft-lb @ 8500 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Gear Ratio:
|
1st 37/13 (2.846) 2nd 37/19 (1.947) 3rd 28/18 (1.556) 4th 32/24 (1.333) 5th 25/21 (1.190) 6th 26/24 (1.083)
|
|
Frame:
|
Aluminium die-cast, diamond shaped
|
|
Front Suspension:
|
43mm Telescopic fork,
|
|
Front Wheel Travel:
|
130 mm / 5.1 in
|
|
Rear Suspension:
|
Swingarm Link less type Monocross,
|
|
Rear Wheel Travel:
|
130 mm / 5.1 in
|
|
Front Brakes:
|
2x 298 mm discs
|
|
Rear Brakes:
|
Single 245 mm disc
|
|
Front Tyre:
|
120/70 ZR17
|
|
Rear Tyre:
|
160/60 ZR17
|
|
Rake:
|
26°
|
|
Trail:
|
103.5 mm / 4.07 in
|
|
Dimensions:
|
Length 2,120mm / 83.5 in Width 770mm / 30.3 in Height 1,185mm / 46.7 in
|
|
Wheelbase:
|
1,440mm / 56.7 in
|
|
Ground Clearance:
|
140 mm / 5.5 in
|
|
Seat Height:
|
785 mm / 30.9 in
|
|
Wet Weight:
|
211 kg / 467 lbs
|
|
Fuel Capacity:
|
17.3 Litres / 4.6 gal
|
