Victory Kingpin Low (2009-10) technical specifications
Victory Kingpin Low is produced in 2009-10. Engine is Four stroke, 50° V twin SOHC, 4 valves per cylinder, displacement 1634 cc / 100 cu-in Victory Kingpin Low weighs 297 kg / 654 lbs. Victory Kingpin Low has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Kingpin Low |
| Years: | 2009-10 |
| Engine: | Four stroke, 50° V twin SOHC, 4 valves per cylinder |
| Capacity: | 1634 cc / 100 cu-in |
| Bore x Stroke: | 101 x 102 mm |
| Cooling System: | Air / oil |
| Compression Ratio: | 9.8:1 |
| Induction: | Electronic Fuel Injection with 44mm throttle bodies |
| Starting: | Electric |
| Battery: | 12 volts / 18 amp hours |
| Clutch: | Wet, multi-plate |
| Transmission: | 6 Speed |
| Final Drive: | Carbon Fiber Reinforced Belt |
| Front Suspension: | 43mm Inverted cartridge telescopic fork |
| Front Wheel Travel: | 130 mm / 5.1 in |
| Rear Suspension: | Single, mono-tube gas forged and cast aluminum w/ rising-rate linkage |
| Rear Wheel Travel: | 100 mm / 3.9 in |
| Front Brakes: | Single 300mm floating rotor 4 piston caliper |
| Rear Brakes: | Single 300mm floating rotor 2 piston caliper |
| Front Tyre: | 130/70 -21 |
| Rear Tyre: | 180/55 B18 |
| Seat Height: | 640 mm / 25.1 in |
| GVWR: | 549 kg / 1210 lbs |
| Dry Weight: | 297 kg / 654 lbs |
| Fuel Capacity: | 17 Litres / 4.5 US gal |
