Victory Jackpot (2012-13) technical specifications

Victory Jackpot is produced in 2012-13. Engine is Four stroke, 50° V twin SOHC, 4 valves per cylinder, displacement 1634 cc / 100 cu-in Victory Jackpot weighs 294 kg / 649 lbs. Victory Jackpot has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Jackpot
Years:	2012-13
Engine:	Four stroke, 50° V twin SOHC, 4 valves per cylinder
Capacity:	1634 cc / 100 cu-in
Bore x Stroke:	101 x 102 mm
Cooling System:	Air / oil
Compression Ratio:	9.8:1
Induction:	Electronic Fuel Injection with 44mm throttle bodies
Starting:	Electric
Battery:	12 volts / 18 amp hours
Clutch:	Wet, multi-plate
Transmission:	6 Speed
Final Drive:	Carbon Fiber Reinforced Belt
Front Suspension:	43mm Inverted cartridge telescopic fork
Front Wheel Travel:	130 mm / 5.1 in
Rear Suspension:	Single, mono-tube gas forged and cast aluminum w/ rising-rate linkage
Rear Wheel Travel:	100 mm / 3.9 in
Front Brakes:	Single 300mm floating rotor 4 piston caliper
Rear Brakes:	Single 300mm floating rotor 2 piston caliper
Front Tyre:	80/90 R21
Rear Tyre:	250/40 R18
Seat Height:	653 mm / 25.7 in
GVWR:	531 kg / 1171 lbs
Dry-Weight:	294 kg / 649 lbs
Fuel Capacity:	17 Litres / 4.5 US gal
