Victory Hammer S (2011-12) technical specifications
Victory Hammer S is produced in 2011-12. Engine is Four stroke, 50° V twin SOHC, 4 valves per cylinder, displacement 1731 cc / 106 cu-in , produces power 96.9 hp / 71.3 kW and 153 Nm / 15.6 kg-m. Victory Hammer S weighs 305 kg / 672 lbs. Victory Hammer S has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Hammer S |
| Years: | 2011-12 |
| Engine: | Four stroke, 50° V twin SOHC, 4 valves per cylinder |
| Capacity: | 1731 cc / 106 cu-in |
| Bore x Stroke: | 101 x 108 mm |
| Cooling System: | Air / oil |
| Compression Ratio: | 9.4:1 |
| Induction: | Fuel Injection with dual 45mm throttle body |
| Oil Capacity: | 5.0 qts / 4.73 ltr |
| Exhaust: | Staggered slash-cut dual exhaust with crossover |
| Battery: | 12 volts / 18 amp hours |
| Starting: | Electric |
| Clutch: | Wet, multi-plate |
| Max Power: | 96.9 hp / 71.3 kW |
| Max Torque: | 153 Nm / 15.6 kg-m |
| Transmission: | 6 Speed |
| Final Drive: | Carbon Fiber Reinforced Belt |
| Primary Drive: | Gear drive with torque compensator |
| Front Suspension: | Inverted cartridge telescopic fork, 43 mm diameter |
| Front Wheel Travel: | 130 mm / 5.1 in |
| Rear Suspension: | Single, mono-tube gas, cast aluminum with rising rate linkage, preload adjustable spring |
| Rear Wheel Travel: | 76 mm / 3.0 in |
| Front Brakes: | Single 300mm floating rotor 4 piston caliper |
| Rear Brakes: | Single 300mm floating rotor 2 piston caliper |
| Front Tyre: | 130/70R18 |
| Rear Tyre: | 250/40R18 |
| Rakem: | 33° |
| Trail: | 140 mm / 5.5 in |
| Dimensions: | Length 93.8 in / 2382 mm |
| Wheelbase: | 1689 mm / 66.5 in |
| Seat Height: | 660 mm / 26 in |
| GVWR: | 532 kg / 1173 lbs |
| Ground Clearance: | 135 mm / 5.3 in |
| Dry Weight: | 305 kg / 672 lbs |
| Fuel Capacity: | 17 Litres / 4.5 US gal |
