Technical specifications
|
| Model: |
125, P125X, PX 125, PX 125 Arcobleno/Lusso, PK125 S, GTS Super |
| Years: |
1977-97 |
|
Engine:
|
Two stroke, single cylinder
|
|
Capacity:
|
123.4 cc 7.5 cub in
|
|
Bore x Stroke:
|
52.5 x 57.0 mm
|
|
Carburetor:
|
Dell,Orto SI 24/24 E
|
|
Compression Ratio:
|
9.2:1
|
|
Cooling:
|
Air cooled, centrifugal fan
|
|
Fuel Mixture:
|
1:50
|
|
Spark Plug:
|
Champion N2C
|
|
Ignition:
|
Flywheel alternator, with built in H.T. coil
|
|
Starting:
|
Kick start
|
|
Clutch:
|
Multiplate
|
|
Max Power:
|
5.9 kW / 8 hp @ 5800 rpm
|
|
Max Torque:
|
10.5 kW / 1.07 kgf-m / 7.7 ft/lb @ 4500 rpm
|
|
Transmission:
|
4 Speed, grip-shift, constant mesh
|
|
Gears:
|
1st 16.4 / 2nd 11.0 / 3rd 7.60 / 4th 5.8:1
|
|
Final Drive:
|
Direct drive
|
|
Frame:
|
Pressed sheet steel, streamlined monocoque structure
|
|
Front Suspension:
|
Helical spring and double acting hydraulic dampers
|
|
Rear Suspension:
|
Helical spring and double acting hydraulic dampers
|
|
Front Brakes:
|
Drum, 125 mm
|
|
Rear Brakes:
|
Drum, 125 mm
|
|
Wheels:
|
Interchangeable
|
|
Front Tyre:
|
3.5 x 10"
|
|
Rear Tyre:
|
3.5 x 10"
|
|
Dimensions:
|
Length: 1655 mm / 65.2 in Width: 790 mm / 31.1 in Height: 1170 mm / 46.4 in
|
|
Wheelbase:
|
1250 mm / 49.2 in
|
|
Turning Radius:
|
1650 mm / 65.0 in.
|
|
Dry Weight:
|
112 kg / 247 lbs
|
|
Fuel Capacity:
|
8 L / 2.1 US gal
|
|
Reserve:
|
1.2 L / 0.55 US gal
|
|
Consumption average:
|
2,7 L/100 km / 37 km/l / 87 US mpg
|
|
Top Speed:
|
100 km/h / 62 mph
|
