Velocette Veloce 2.25 hp (1909-18) technical specifications
Velocette Veloce 2.25 hp is produced in 1909-18. Engine is Two-stroke, single cylinder, displacement 206 cc / 12.6 cub in , produces power 2.7 kW / 3.65 hp @ 2800 rpm. Velocette Veloce 2.25 hp wet weight is Belt drive: 46.2 kg / 102 lbs Chain drive: 52.6 kg / 116 lbs. Velocette Veloce 2.25 hp has 3 photos.
Technical specifications
+ Add to 'Compare list'Model: | Veloce 2.25 hp |
Years: | 1909-18 |
Engine: | Two-stroke, single cylinder |
Capacity: | 206 cc / 12.6 cub in |
Bore x Stroke: | 60.3 x 73 mm |
Cooling System: | Air cooled |
Lubrication: | Mechanical lubrication |
Carburetor: | AMAC, compression release from handle bar |
Exhaust: | Exhaust valve lifter operated by Bowden wire from handle bar, steel silencer |
Ignition: | Bosch or UH Magneto waterproof type, magneto control from tank |
Starting: | Pedal |
Max Power: | 2.7 kW / 3.65 hp @ 2800 rpm |
Transmission: | ¾ in V-shape belt, rubber, Dunlop Two speed: chain |
Final Drive: | Belt or chain |
Gear Ratio: | Belt drive: 6:1 Chain drive: 1st 11.0 / 2nd 5.5:1, gearshift from handle bar |
Frame: | Special design, low position |
Front Suspension: | Druid Patent, spring forks |
Rear Suspension: | Spring loaded seat |
Front Brakes: | Bowden |
Rear Brakes: | Foot operated belt rim brake |
Wheels: | Spoked |
Front Tyre: | Dunlop studded 2 x 24" BE |
Rear Tyre: | Dunlop studded 2 x 24" BE |
Saddle height: | 711 mm / 28 in |
Saddle: | Gough |
Fuel Capacity: | 3.8 L / 1 US gal |
Wet Weight: | Belt drive: 46.2 kg / 102 lbs Chain drive: 52.6 kg / 116 lbs |
Tool Bag: | Fitted with complete tool kit |
Colours: | Enamel black, with decorated tank |
Source: | Velocetteowners.com, Veloce Brochure, 1913 |
