Technical specifications
|
| Model: |
M70 |
| Years: |
2015 |
|
Engine:
|
Four stroke, twin flat boxer cylinders, OHV, 2 valve percylinder
|
|
Capacity:
|
749 cc / 45.7 cub in
|
|
Bore x Stroke:
|
78 x 78 mm
|
|
Compression Ratio:
|
8.6:1
|
|
Cooling System:
|
Air cooled
|
|
Induction:
|
Throttle body, EFI
|
|
Starting:
|
Electric & kick
|
|
Spark Plug:
|
NGK BPR6HS
|
|
Max Power:
|
30.6 kW / 41 hp @ 5500 rpm
|
|
Max Torque:
|
56.9 Nm / 5.8 kgf-m / 42 ft-lbs @ 4300 rpm
|
|
Clutch:
|
Dry, double disc
|
|
Transmission:
|
4 speed with reverse
|
|
Final Drive:
|
Shaft
|
|
Sidecar drive:
|
None
|
|
Final Drive Ratio:
|
4.62:1
|
|
Front Suspension:
|
40mm Marzocchi telescopic forks
|
|
Rear Suspension:
|
Double sided swing-arm with two Sachs hydraulic spring shock absorbers, 5x adjustable Sidecar: Single sided swing-arm with Sachs hydraulic spring shock absorber, 5x adjustable
|
|
Front Wheels:
|
Aluminium rims with spokes, 2.5 x 18
|
|
Rear Wheels:
|
2 x Aluminium rims with spokes, 2.5 x 18
|
|
Front Tyres:
|
4.0 x 18, Heidenau
|
|
Rear Tyres:
|
2 x 4.0 x 18, Heidenau
|
|
Front Brakes:
|
295 mm floating NG disc, Brembo 4-piston fixed caliper
|
|
Rear Brakes:
|
256 mm fixed NG disc, HB big bore single piston floating caliper Sidecar: 245 mm floating NG disc, Brembo 2-piston fixed caliper
|
|
Dimensions:
|
Length: 2449 mm / 94.6 in Width: 1582 mm / 62.3 in Height: 1356 mm / 53.4 in
|
|
Ground clearance:
|
124.5 mm / 4.9 in
|
|
Seat Height:
|
749 mm / 29.5 in
|
|
Dry Weight:
|
322 kg / 710 lbs
|
|
Max Permissible Weight:
|
517 kg / 1140 lbs
|
|
Fuel Capacity:
|
20.8 L / 5.5 US gal
|
|
Fuel Reserve:
|
3.8 L / 1.0 US gal
|
|
Consumption Average:
|
6.7 L/100km / 14.9 km/l / 35 US mpg
|
|
Colours:
|
By order
|
