Triumph Tiger 800 XCx (2017-18) technical specifications
Triumph Tiger 800 XCx is produced in 2017-18. Engine is Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder., displacement 799 cc / 48.7 cub in , produces power 70.8 KW / 95 hp @ 9250 rpm and 79 Nm / 8.1 kgf-m / 58 ft.lb @ 7850 rpm. Triumph Tiger 800 XCx weighs 215 kg / 474 lbs. Triumph Tiger 800 XCx has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Tiger 800 XCx |
| Years: | 2017-18 |
| Engine: | Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder. |
| Capacity: | 799 cc / 48.7 cub in |
| Bore x Stroke: | 74 x 61.9 mm |
| Compression: | 11.3:1 |
| Cooling System: | Liquid cooled |
| Lubrication: | Wet sump |
| Oil Capacity: | 3.7 L / 0.98 US gal |
| Induction: | Multipoint sequential electronic fuel injection |
| Ignition: | Digital CDI |
| Starting: | Electric |
| Exhaust: | Stainless Steel, 3 into 1, high-level stainless steel silencer |
| Clutch: | Wet, multi-plate |
| Max Power: | 70.8 KW / 95 hp @ 9250 rpm |
| Max Torque: | 79 Nm / 8.1 kgf-m / 58 ft.lb @ 7850 rpm |
| Transmission: | 6 Speed |
| Final Drive: | Chain, O-ring |
| Frame: | Tubular steel trellis frame, swingarm: twin-sided, cast aluminum alloy |
| Front Suspension: | WP 43mm upside down forks, adjustable rebound and compression |
| Front Wheel Travel: | 220 mm / 8.7 in |
| Rear Suspension: | WP monoshock with remote oil reservoir, hudraulically adjustable preload, rebound |
| Rear Wheel Travel: | 215 mm / 8.5 in |
| Front Brakes: | 2 x 308 mm floating discs, Nissin 2-piston sliding calipers, switchable ABS |
| Rear Brakes: | Single 255 mm disc, Nissin single-piston sliding caliper, Switchable ABS |
| Front Wheel: | 36-Spoke 21 x 2.5 in, aluminium rim |
| Rear Wheel: | 32-Spoke 17 x 4.25 in, aluminium rim |
| Front Tyre: | 90/90 R21 |
| Rear Tyre: | 150/70 R17 |
| Rake: | 24.3° |
| Trail: | 95.3 mm / 3.75 in |
| Dimensions: | Length 2215 mm / 87.1in Width 845 mm / 33.3 in (with handlebars) Height 1390 mm / 54.7 in (without mirrors) |
| Wheelbase: | 1545 mm / 60.8 in |
| Seat Height: | 840 mm - 860 mm / 33.1 in- 33.9 in adjustable |
| Dry Weight: | 215 kg / 474 lbs |
| Fuel Capacity: | 19 Litres / 5.0 US gal / 4.2 Imp gal |
