Triumph Street Triple RS (2020) technical specifications

Triumph Street Triple RS is produced in 2020. Engine is Four stroke, in-line 3-cylinder, DOHC, 4 valve per cylinder, displacement 765 cc / 46.6 cu-in , produces power 121.3 hp / 123 PS / 90 kW @ 11,750 rpm and 79 Nm / 58.3 lb-ft @ 9,350 rpm. Triumph Street Triple RS weighs 166 kg / 366 lbs. Triumph Street Triple RS has 10 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Street Triple RS
Years:	2020
Engine:	Four stroke, in-line 3-cylinder, DOHC, 4 valve per cylinder
Capacity:	765 cc / 46.6 cu-in
Bore x Stroke:	78 x 53.4 mm
Cooling System:	Liquid-cooled
Compression Ratio:	12.54:1
Lubrication:	Wet sump
Induction:	Multipoint sequential electronic fuel injection with SAI. Electronic throttle control
Exhaust:	Stainless steel 3 into 1 exhaust system low single sided stainless steel silencer
Emission:	Euro 5
Ignition:	Digital - inductive type
Starting:	Electric
Max Power:	121.3 hp / 123 PS / 90 kW @ 11,750 rpm
Max Torque:	79 Nm / 58.3 lb-ft @ 9,350 rpm
Clutch:	Wet, multi-plate, slip-assisted
Transmission:	6 Speed with Triumph Shift Assist
Final Drive:	X ring chain
Frame:	Front - Aluminum beam twin spar Rear - 2 piece high pressure die cast
Swingarm:	Twin-sided, cast aluminum alloy
Front Suspension:	Showa 41 mm upside down big piston forks (BPF), Adjustable compression damping, rebound damping and preload adjustment
Front Wheel Travel:	115 mm / 4.5 in
Rear Suspension:	Öhlins STX40 fully-adjustable piggyback reservoir RSU
Rear Wheel Travel:	131 mm / 5.2 in
Front Brakes:	2 x 310mm floating discs, Brembo M50 4-piston monobloc calipers
Rear Brakes:	Single 220mm disc, Brembo single-piston caliper
ABS:	Adjustable ABS
Wheels:	5-spoke cast aluminum alloy
Front Wheels:	3.5 x 17
Rear Wheels:	5.5 x 17
Front Tyre:	120/70 ZR17 Pirelli Diablo Supercorsa SP V3
Rear Tyre:	180/55 ZR17 Pirelli Diablo Supercorsa SP V3
Rake:	23.9º
Trail:	100 mm / 3.9 in
Dimensions:	Width 775 mm / 30.5 in - with handlebars Height 1085 mm / 42.7 in - without mirrors
Wheelbase:	1405 mm / 55.3 in
Seat Height:	825 mm / 32.5 in
Dry Weight:	166 kg / 366 lbs
Fuel Capacity:	17.4 Litres / 4.6 US gal / 3.8 Imp gal
