Triumph Sprint ST (2002) technical specifications
Triumph Sprint ST is produced in 2002. Engine is Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder, displacement 955 cc / 58.3 cu in , produces power 87.5 kW / 120 hp @ 9100 rpm and 100 Nm / 10.2 kg-m / 74 ft-lb @ 5100 rpm. Triumph Sprint ST top speed is 231 km/h / 143.5 mph. Triumph Sprint ST wet weight is 249 kg / 456 lbs. Triumph Sprint ST has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Sprint ST |
| Years: | 2002 |
| Engine: | Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder |
| Capacity: | 955 cc / 58.3 cu in |
| Cooling System: | Liquid cooled |
| Bore x Stroke: | 79 x 65 mm |
| Lubrication: | Wet sump |
| Compression Ratio: | 12.0:1 |
| Induction: | Multipoint sequential electronic fuel injection |
| Engine Oil: | Synthetic, 10W/40 |
| Ignition: | Digital CDI |
| Spark Plug: | NGK, CR9EK |
| Starting: | Electric |
| Battery: | 12V, 12Ah |
| Max Power: | 87.5 kW / 120 hp @ 9100 rpm |
| Max Torque: | 100 Nm / 10.2 kg-m / 74 ft-lb @ 5100 rpm |
| Clutch: | Wet, multiple discs, cable operated |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Frame: | Aluminium, twin spar |
| Front Suspension: | 45 mm Forks with dual rate springs and adjustable preload |
| Front Wheel travel: | 127 mm / 5.0 in |
| Rear Suspension: | Monoshock with adjustable preload, compression and rebound damping |
| Rear Wheel travel: | 147 mm / 5.8 in |
| Front Brakes: | 2 x 320 mm Discs, 4 piston calipers |
| Rear Brakes: | Single 255 mm disc, 2 piston caliper |
| Wheels Front: | Alloy 3 spoke, 17 x 3.5 in |
| Wheels Rear: | Alloy 3 spoke, 17 x 6.0 in |
| Front Tyre: | 120/70 ZR17 |
| Rear Tyre: | 180/55 ZZR17 |
| Rake: | 25.3º |
| Trail: | 94 mm / 3.7 in |
| Dimensions: | Length 2160 mm / 85.0 in Width 735 mm / 28.9 in (handlebars) Height 1220 mm / 48.0 in |
| Wheelbase: | 1470 mm / 57.9 in |
| Seat Height: | 800 mm / 31.5 in |
| Wet Weight: | 249 kg / 456 lbs |
| GVWR: | 453 kg / 999 lbs |
| Fuel Capacity: | 19.5 Litres / 5.2 US gal / 4.3 Imp gal |
| Fuel Reserve: | 1.1 Litres / 0.3 US gal / 0.2 Imp gal |
| Consumption Average: | 6.5 L/100 km / 15.3 km/l / 36 US mpg / 43.2 Imp mpg |
| Standing ¼ Mile: | 11.0 sec |
| Top Speed: | 231 km/h / 143.5 mph |
