Technical specifications
|
| Model: |
Sprint GT |
| Years: |
2011 |
|
Engine:
|
Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder.
|
|
Capacity:
|
1050 cc / 64.1 cu in
|
|
Bore x Stroke:
|
79 x 71.4mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
12.0:1
|
|
Lubrication:
|
Wet sump
|
|
Engine Oil:
|
Synthetic, 10W/40 Synthetic
|
|
Induction:
|
Multipoint sequential electronic fuel injection with SAI
|
|
Ignition:
|
Digital
|
|
Spark Plug:
|
NGK, CR9EK
|
|
Starting:
|
Electric
|
|
Max Power:
|
96 kW / 128 hp @ 9200 rpm
|
|
Max Torque:
|
108 Nm / 11.0 kgf-m / 80 ft-lb @ 6300 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Aluminium beam perimeter, swingarm single-sided, aluminium alloy with eccentric chain adjuster
|
|
Front Suspension:
|
Showa 43mm cartridge forks with dual rate springs and adjustable preload
|
|
Front Wheel Travel:
|
127 mm / 5.0 in
|
|
Rear Suspension:
|
Showa monoshock with adjustable preload and rebound damping
|
|
Rear Wheel Travel:
|
152 mm / 6.0 in
|
|
Front Brakes:
|
2 x 320 mm Floating discs, 4 piston calipers, ABS
|
|
Rear Brakes:
|
Single 255 mm disc, 2 piston caliper, ABS
|
|
Front Wheel:
|
Cast aluminium alloy 5-spoke 17 x 3.50 in
|
|
Rear Wheels:
|
Cast aluminium alloy 5-spoke 17 x 5.50 in
|
|
Front Tyre:
|
120/70-ZR17
|
|
Rear Tyre:
|
180/55-ZR17
|
|
Dimensions:
|
Length 2260 mm / 88.9 in Width (handlebars) 760 mm / 29.9 in Height without mirrors 1210 mm / 47.6 in
|
|
Seat Height:
|
815 mm / 32.1 in
|
|
Rake:
|
23.5º
|
|
Trail:
|
84 mm / 3.3 in
|
|
Wheelbase:
|
1537 mm / 60.5 in
|
|
Dry Weight:
|
239 kg / 527 lbs
|
|
Wet Weight:
|
265 kg / 584.2 lbs
|
|
Fuel Capacity:
|
20 Litres / 5.3 US gal / 4.4 Imp gal
|
