Triumph Speed Triple R Dark (2013) technical specifications

Triumph Speed Triple R Dark is produced in 2013. Engine is Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder, displacement 1050 cc / 64.1 cub in , produces power 99 kW / 133 hp @ 9400 rpm and 111 Nm / 11.3 kgf-m / 82 ft.lbs @ 7750rpm. Triumph Speed Triple R Dark top speed is 253.8 km/h/ 157.7 mph. Triumph Speed Triple R Dark wet weight is 212 kg / 466 lbs. Triumph Speed Triple R Dark has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Speed Triple R Dark
Years:	2013
Production:	30 Units
Engine:	Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder
Capacity:	1050 cc / 64.1 cub in
Bore x Stroke:	79 x 71.4 mm
Cooling System:	Liquid-cooled
Compression Ratio:	12.0:1
Induction:	Multipoint sequential electronic fuel injection with SAI
Engine Oil:	10W/40 Synthetic
Exhaust:	Stainless Steel 3 into 1 into 2, twin high level stainless steel silencers
Ignition:	Digital–inductive type via electronic engine management system
Spark Plug:	NGK CR9EK
Starting:	Electric
Max Power:	99 kW / 133 hp @ 9400 rpm
Max Torque:	111 Nm / 11.3 kgf-m / 82 ft.lbs @ 7750rpm
Clutch:	Wet, multi-plate
Transmission:	6 Speed
Final Drive:	X ring chain
Frame:	Aluminium beam twin-spar
Front Suspension:	Öhlins 43 mm NIX30 upside down forks with adjustable rebound and compression damping,
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Öhlins TTX36 twin tube monoshock with rebound and compression damping
Rear Wheel Travel:	130 mm / 5.1 in
Front Brakes:	2 x 320 mm Discs, 4 piston radial monoblock calipers, Brembo, switchable ABS
Rear Brakes:	Single 255 mm disc, 2 piston caliper, Nissen, switchable ABS
Wheel Front:	Forged aluminium alloy 5 spoke, 17 x 3.5 in
Wheel Rear:	Forged aluminium alloy 5 spoke, 17 x 6.0 in
Front Tyre:	120/70 ZR 17
Rear Tyre:	190/55 ZR 17
Rake:	22.8°
Trail:	90.9 mm / 3.6 in
Dimensions:	Length 2100mm / 82.6in Width (handlebars) 795mm / 31.3in Height without mirrors 1110mm / 43.7in
Wheelbase:	1435 mm / 56.5in
Seat Height:	825 mm / 32.5 in
Wet Weight:	212 kg / 466 lbs
Fuel Capacity:	17.5 Litres / 4.6 US gal / 3.8 Imp gal
Consumption Average:	5.95 L/100 km / 16.8 km/l / 39.5 US mpg / 47.5 Imp mpg
Standing ¼ Mile:	11.3 sec
Top Speed:	253.8 km/h/ 157.7 mph
Review:	Cycle World
