Technical specifications
|
| Model: |
Bonneville T120 |
| Years: |
2019 |
|
Engine:
|
Four stoke, parallel twin, 270o crank, SOHC 4 valves per cylinder
|
|
Capacity:
|
1198 cc / 73.1 cu in
|
|
Bore x Stroke:
|
97.6 x 80 mm
|
|
Compression Ratio:
|
10.0:1
|
|
Cooling System:
|
Liquid cooled
|
|
Lubrication:
|
Wet sump
|
|
Exhaust:
|
Chromed 2 into 2 exhaust system with twin chrome silencers,
|
|
Emission:
|
EURO 4 compliant
|
|
Induction:
|
Multipoint sequential electronic fuel injection
|
|
Ignition:
|
Digital
|
|
Starting:
|
Electric
|
|
Max Power:
|
59 kW / 80 hp @ 6550 rpm
|
|
Max Torque:
|
105 Nm / 10.7 kgf-m / 77.4 lb-ft @ 3100 rpm
|
|
Clutch:
|
Wet, multi-plate
|
|
Transmission:
|
6-Speed
|
|
Final Drive:
|
Chain, X-ring
|
|
Frame:
|
Dual tubular steel cradle
|
|
Front Suspension:
|
Kayaba 41 mm forks
|
|
Front Wheel Travel:
|
120 mm / 4.7 in
|
|
Rear Suspension:
|
Kayaba twin shocks with adjustable preload
|
|
Rear Wheel Travel:
|
120 mm / 4.7 in
|
|
Front Brakes:
|
2 x 310 mm discs, 2 piston floating Nissin calipers
|
|
Rear Brakes:
|
Single 255 mm disc, 2 piston floating Nissin caliper
|
|
ABS:
|
Standard
|
|
Wheels Front:
|
2.75 x 18, 32 spokes
|
|
Wheels Rear:
|
4.25 x 17, 32 spokes
|
|
Front Tyre:
|
100/90-18
|
|
Rear Tyre:
|
150/70 R17
|
|
Rake:
|
25.5o
|
|
Trail:
|
105.2 mm / 4.1 in
|
|
Dimensions:
|
Length: 2170 mm / 85.4 in Width: 785 mm / 30.9 in Height: 1125 mm / 44.3 in
|
|
Wheelbase:
|
1445 mm / 56.9 in
|
|
Seat Height:
|
785 mm / 30.9 in
|
|
Dry Weight:
|
224 kg / 494 lbs
|
|
Fuel Capacity:
|
14.4 Litres / 3.8 US gal / 3.2 Imp gal
|
