Triumph Bonneville T100 (2021) technical specifications

Triumph Bonneville T100 is produced in 2021. Engine is Four stroke, 270° Crank angle parallel twin, SOHC, 4 valves per cylinder, displacement 900 cc / 54.9 cu in , produces power 47.8 kW / 64.1 hp @ 7400 rpm and 80 Nm / 59 ft-lb @ 3750 rpm. Triumph Bonneville T100 wet weight is 228 kg / 503 lbs. Triumph Bonneville T100 has 8 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Bonneville T100
Years:	2021
Engine:	Four stroke, 270° Crank angle parallel twin, SOHC, 4 valves per cylinder
Capacity:	900 cc / 54.9 cu in
Bore x Stroke:	84.6 x 80 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.0:1
Lubrication:	Wet sump
Exhaust:	Brushed stainless steel 2 into 2 exhaust system with twin silencers
Induction:	Multipoint sequential electronic fuel injection
Emission:	EURO5
Ignition:	Digital
Starting:	Electric
Max Power:	47.8 kW / 64.1 hp @ 7400 rpm
Max Torque:	80 Nm / 59 ft-lb @ 3750 rpm
Clutch:	Wet, multi plate, torque assist clutch
Transmission:	5 Speed
Final Drive:	Chain, X-ring
Frame:	Tubular steel, twin cradle
Swingarm:	Twin sided fabrication
Front Suspension:	41mm Kayaba cartridge forks
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Twin RSUs, with pre-load adjustment
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	Single 310 mm floating disc, Brembo 2 piston axial caliper
Rear Brakes:	Single 255 mm disc, Nissin 2 piston floating caliper, ABS
ABS:	Standard
Wheels Front:	32 Spokes, 18 x 2.75 in
Wheels Rear:	32 Spokes, 17 x 4.25 in
Front Tyre:	100/90-R18
Rear Tyre:	150/70-R17
Rake:	25.5°
Trail:	104 mm / 4.1 in
Dimensions:	Length: 2170 mm / 85.4 in Width: 780 mm / 30.7 in Height: 1100 mm / 43.3 in
Wheelbase:	1450 mm / 57.1 in
Seat Height:	790 mm / 31.1 in
Wet Weight:	228 kg / 503 lbs
Fuel Capacity:	14.5 Litres / 3.8 US gal
Instuments:	Twin dial analogue speedometer and tachometer with LCD multi-functional displays
