Triumph Bonneville Elvis Presley Limited Edition (2024) technical specifications
![Triumph Bonneville Elvis Presley Limited Edition technical specifications Triumph Bonneville Elvis Presley Limited Edition technical specifications](https://www.moto-data.net/media/triumph/pics/triumph-bonneville-elvis-presley-limited-edition-2024[1].jpg)
Triumph Bonneville Elvis Presley Limited Edition is produced in 2024. Engine is Four stoke, parallel twin, 270? crank, SOHC, 4 valves per cylinder, displacement 1198 cc / 73.1 cu-in , produces power 58.8 kW / 78.9 hp @ 6550 rpm and 105 Nm / 77.4 lb-ft @ 3500 rpm. Triumph Bonneville Elvis Presley Limited Edition wet weight is 236 kg / 520 lbs. Triumph Bonneville Elvis Presley Limited Edition has 6 photos.
Technical specifications
+ Add to 'Compare list'Model: | Bonneville Elvis Presley Limited Edition |
Years: | 2024 |
Production: | 925 units |
Engine: | Four stoke, parallel twin, 270? crank, SOHC, 4 valves per cylinder |
Capacity: | 1198 cc / 73.1 cu-in |
Bore x Stroke: | 97.6 x 80 mm |
Compression Ratio: | 10.0:1 |
Cooling System: | Liquid cooled |
Lubrication: | Wet sump |
Exhaust: | Chromed 2 into 2 exhaust system with twin chrome silencers |
Ignition: | Digital |
Emisson: | Euro 5 |
Induction: | Multipoint sequential electronic fuel injection |
Starting: | Electric |
Max Power: | 58.8 kW / 78.9 hp @ 6550 rpm |
Max Torque: | 105 Nm / 77.4 lb-ft @ 3500 rpm |
Clutch: | Wet, multi-plate, torque assist clutch |
Transmission: | 6-Speed |
Final Drive: | Chain, X-ring |
Frame: | Tubular steel, twin cradle |
Swingarm: | Twin sided fabrication |
Front Suspension: | Kayaba 41 mm cartridge forks |
Front Wheel Travel: | 120 mm / 4.7 in |
Rear Suspension: | Twin RSUs, with pre-load adjustment |
Rear Wheel Travel: | 120 mm / 4.7 in |
Front Brakes: | 2 x 310mm discs, Brembo 2 piston floating caliper |
Rear Brakes: | Single 255mm disc, Nissin 2 piston floating caliper |
ABS: | Standard |
Wheels: | Lightweight 32-spoke wire wheels with aluminum rims |
Wheels Front: | 18 x 2.75 in |
Wheels Rear: | 17 x 4.25 in |
Front Tyre: | 100/90-18 |
Rear Tyre: | 150/70 R17 |
Rake: | 25.5? |
Trail: | 105.2 mm / 4.1 in |
Dimensions: | Length: 2170 mm / 85.4 in Width: 780 mm / 30.7 in Height: 1100 mm / 43.3 in |
Wheelbase: | 1450 mm / 57.1 in |
Seat Height: | 790 mm / 31.1 in |
Wet Weight: | 236 kg / 520 lbs |
Fuel Capacity: | 14.5 Litres / 3.8 US gal |
Instruments: | Twin dial analogue speedometer and tachometer with LCD multi-functional displays |
