Triumph America LT (2015-16) technical specifications
Triumph America LT is produced in 2015-16. Engine is Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, 360° firing interval, displacement 865 cc / 52.8 cub in. , produces power 45.5 kW / 61 hp @ 6800 rpm and 72 Nm / 7.34 kgf-m / 53.1 ft-lb @ 3300 rpm. Triumph America LT wet weight is 270 kg / 595 lbs. Triumph America LT has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | America LT |
| Years: | 2015-16 |
| Engine: | Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, 360° firing interval |
| Capacity: | 865 cc / 52.8 cub in. |
| Bore x Stroke: | 90 x 68 mm |
| Cooling System: | Air-cooled |
| Compression Ratio: | 9.2:1 |
| Induction: | Twin carburettors, with throttle position sensor and electric carburettor heaters |
| Lubrication: | Wet sump |
| Engine Oil: | Synthetic, 15W/50 |
| Oil Capacity: | 4.5 L / 1.2 US gal / 1.0 Imp gal |
| Exhaust: | Stainless steel twin-walled headers, twin chromed silencers |
| Ignition: | Digital |
| Starting: | Electric |
| Max Power: | 45.5 kW / 61 hp @ 6800 rpm |
| Max Torque: | 72 Nm / 7.34 kgf-m / 53.1 ft-lb @ 3300 rpm |
| Clutch: | Wet multi plate |
| Transmission: | 5 Speed |
| Final Drive: | Chain, X-ring |
| Frame: | Tubular steel cradle, swing arm: twin-sided, tubular steel |
| Front Suspension: | 41mm Kayaba telescopic forks, polished stainless steel shrouds |
| Front Wheel Travel: | 120 mm / 4.7 in |
| Rear Suspension: | Kayaba chrome spring twin shocks with adjustable preload |
| Rear Wheel Travel: | 96 mm / 3.8 in |
| Front Brakes: | Single 310 mm disc, Nissin 2 piston floating caliper |
| Rear Brakes: | Single 285 mm disc, Nissin 2 piston floating caliper |
| Wheels Front: | Cast aluminum alloy, 12 spoke, 16 x 3.0 inch |
| Wheels Rear: | Cast aluminum alloy, 12 spoke, 15 x 4.0 inch |
| Front Tyre: | 130/90 - 16 |
| Rear Tyre: | 170/80 B15 |
| Rake: | 33.3° |
| Trail: | 143 mm / 5.6 in |
| Dimensions: | Length 2387 mm / 94.0 in Width 920 mm / 36.2 in (at handlebars) Height 1480 mm / 58.3 in (with screen) |
| Wheelbase: | 1610 mm / 63.4 in |
| Seat Height: | 690 mm / 27.2 in |
| Wet Weight: | 270 kg / 595 lbs |
| Fuel Capacity: | 19.3 Litres / 5.1 US gal / 4.2 Imp gal |
