Suzuki TS 250 (1976-77) technical specifications
Suzuki TS 250 is produced in 1976-77. Engine is Two stroke, single cylinder, reed valve, displacement 246 cc / 15.0 cu in , produces power 17.2 kW / 23 hp @ 6500 rpm and 26.5 Nm / 2.7 kgf-m / 19.6 lb-ft @ 5000 rpm. Suzuki TS 250 weighs 111 kg / 245 lbs. Suzuki TS 250 has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | TS 250 |
| Years: | 1976-77 |
| Engine: | Two stroke, single cylinder, reed valve |
| Capacity: | 246 cc / 15.0 cu in |
| Bore x Stroke: | 72 x 64 mm |
| Compression Ratio: | 6.5:1 |
| Cooling System: | Air cooled |
| Lubrication System: | Fuel/oil mix, Posi-force, CCI |
| Exhaust: | Single, high drawn |
| Induction: | Mikuni VN28SS carburetor |
| Ignition: | Suzuki PEI |
| Starting: | Kick |
| Max Power: | 17.2 kW / 23 hp @ 6500 rpm |
| Max Torque: | 26.5 Nm / 2.7 kgf-m / 19.6 lb-ft @ 5000 rpm |
| Clutch: | Wet, multi-plate |
| Transmission: | 5 Speed, constant mesh |
| Final Drive: | Chain |
| Frame: | Double cradle, tubular steel |
| Front Suspension: | Telescopic fork, oil damped |
| Front Wheel Travel: | 175 mm / 6.9 in |
| Rear Suspension: | Swingarm, dual shocks, coil springs, 5-way adjustable |
| Front Brakes: | Drum, internal expanding |
| Rear Brakes: | Drum, internal expanding |
| Front Tyre: | 3.25-19 4PR Trails |
| Rear Tyre: | 4.00-18 4PR Trails |
| Dimensions: | Length: 2184 mm / 86.0 in Width: 889 mm / 35.0 in Height: 1100 mm / 43.3 in |
| Wheelbase: | 1415 mm / 55.7 in |
| Ground Clearance: | 249 mm / 9.8 in |
| Dry Weight: | 111 kg / 245 lbs |
| Oil Capacity: | 1.1 L / 2.3 US pt / 1.9 Imp pt |
| Fuel Capacity: | 9.1 L / 2.4 US gal / 2.0 Imp gal |
| Top Speed (est.): | 129 km/h / 80 mph |
