Technical specifications
|
| Model: |
TS 125 |
| Years: |
1992-96 |
|
Engine:
|
Two stroke, single cylinder, 4 valves
|
|
Capacity:
|
124 cc / 7.58 cu in
|
|
Bore x Stroke:
|
56 x 50.6 mm
|
|
Compression Ratio:
|
7.1:1
|
|
Cooling System:
|
Liquid cooled
|
|
Lubrication System:
|
Wet sump
|
|
Ignition:
|
Digital CDI
|
|
Starting:
|
Kick
|
|
Spark Plug:
|
NGK, BR9ES
|
|
Max Power:
|
16.4 kW / 22 hp @ 8000 rpm
|
|
Max Torque:
|
18.6 Nm / 1.9 kgf-m / 13.7 lb-ft @ 7500 rpm.
|
|
Clutch:
|
Wet, multi-plate, cable operated
|
|
Transmission:
|
6-Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
Telescopic fork
|
|
Rear Suspension:
|
Swingarm, mono-shock
|
|
Front Brakes:
|
Single disc
|
|
Rear Brakes:
|
Single disc
|
|
Front Tyre:
|
2.75-21
|
|
Rear Tyre:
|
4.10-18
|
|
Dimensions:
|
Length: 2165 mm / 85.2 in Width: 880 mm / 34.6 in Height: 1215 mm / 47.8 in
|
|
Wheelbase:
|
1415 mm / 55.7 in
|
|
Ground Clearance:
|
290 mm / 11.4 in
|
|
Seat Height:
|
860 mm / 33.9 in
|
|
Dry Weight:
|
100 kg / 220 lbs
|
|
Wet Weight:
|
110 kg / 243 lbs
|
|
Fuel Capacity:
|
9 L / 2.4 US gal / 2.0 Imp gal
|
|
Road Tests:
|
Moto Sprint 1989 Group Test
|
