Suzuki TS 125 (1974-76) technical specifications

Suzuki TS 125 technical specifications

Suzuki TS 125 is produced in 1974-76. Engine is Two stroke, single cylinder, displacement 123 cc / 7.5 cu in , produces power 10.4 kW / 14 hp @ 7000 rpm and 14.7 Nm / 1.5 kgf-m / 10.8 lb-ft @ 6000 rpm.. Suzuki TS 125 top speed is 105 km/h / 65 mph. Suzuki TS 125 weighs 90 kg / 198 lbs. Suzuki TS 125 has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: TS 125
Years: 1974-76
Engine: Two stroke, single cylinder
Capacity: 123 cc / 7.5 cu in
Bore x Stroke: 56 x 50 mm
Compression Ratio: 6.7:1
Cooling System: Air cooled
Lubrication System: CCI automatic lube
Starting: Kick
Max Power: 10.4 kW / 14 hp @ 7000 rpm
Max Torque: 14.7 Nm / 1.5 kgf-m / 10.8 lb-ft @ 6000 rpm.
Transmission: 5 Speed
Final Drive: Chain
Front Suspension: Telescopic fork
Rear Suspension: Swingarm, twin shocks, 5-way adjustable
Front Brakes: Drum
Rear Brakes: Drum
Front Tyre: 2.75-19
Rear Tyre: 3.25-18
Dimensions: Length: 2050 mm / 80.7 in Width: 770 mm / 30.3 in Height: 1100 mm / 43.3 in
Wheelbase: 1310 mm / 51.6 in
Ground Clearance: 236 mm / 9.3 in
Climbing Ability: 34o
Dry Weight: 90 kg / 198 lbs
Fuel Capacity: 9.5 Litres / 2.5 US gal / 2.1 Imp gal
Standing ¼ Mile: 19.6 sec
Top Speed: 105 km/h / 65 mph
