Suzuki SV 650 (2016-17) technical specifications
Suzuki SV 650 is produced in 2016-17. Engine is Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder, displacement 645 cc / 39.3 cu in , produces power 56 kW / 75 hp @ 8500 rpm and 64 Nm / 6.5 kgf-m / 47.2 lb-ft @ 8100 rpm. Suzuki SV 650 weighs Non ABS: 195 kg / 430 lbs, ABS: 197 kg / 434 lbs. Suzuki SV 650 has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | SV 650 |
| Years: | 2016-17 |
| Engine: | Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder |
| Capacity: | 645 cc / 39.3 cu in |
| Bore x Stroke: | 81 x 62.6 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 11.2:1 |
| Lubrication: | Wet sump |
| Induction: | Fuel Injection, 39mm throttle bodies |
| Ignition: | Electronic ignition (Transistorized) |
| Starting: | Electric |
| Max Power: | 56 kW / 75 hp @ 8500 rpm |
| Max Torque: | 64 Nm / 6.5 kgf-m / 47.2 lb-ft @ 8100 rpm |
| Transmission: | 6 Speed, constant mesh |
| Final Drive: | Chain, DID525V8, 114 links |
| Frame: | Compact trellis steel frame |
| Rake: | 25o |
| Trail: | 104 mm / 4.1 in |
| Front Suspension: | Telescopic fork, coil spring, oil damped |
| Front Wheel Travel: | 125 mm / 4.9 in |
| Rear Suspension: | Link type, coil spring, oil damped, spring preload 7-step adjustable |
| Rear Wheel Travel: | 130 mm / 5.1 in |
| Front Brakes: | 2 x 290 mm Discs, 2 piston calipers, / ABS |
| Rear Brakes: | Single 240 mm disc, 1 piston caliper, / ABS |
| Front Wheel: | 3.50 x 17, Aluminium alloy, 5-spoke |
| Rear Wheel: | 5.00 x 17, Aluminium alloy, 5-spoke |
| Front Tyre: | 120/70 ZR17M/C 58W, tubeless |
| Rear Tyre: | 160/60 ZR17M/C 69W, tubeless |
| Dimensions: | Length 2140 mm / 84.2 in Width 760 mm / 29.9 in Height 1090mm / 42.9 in |
| Wheelbase: | 1445 mm / 56.9 in |
| Seat Height: | 785 mm / 30.9 in |
| Ground clearance: | 135mm / 5.3 in |
| Dry Weight: | Non ABS: 195 kg / 430 lbs, ABS: 197 kg / 434 lbs |
| Fuel Capacity: | 14.5 Litres / 3.8 US gal / 3.2 Imp gal |
