Technical specifications
|
| Model: |
SP 600 |
| Years: |
1985 |
|
Engine:
|
Four stroke, single cylinder, SOHC, 4 valves per cylinder
|
|
Capacity:
|
589 cc / 35.9 cu in
|
|
Bore x Stroke:
|
94 x 85 mm
|
|
Compression Ratio:
|
8.5:1
|
|
Cooling System:
|
Air/oil cooled
|
|
Induction:
|
Mikuni BS40SS carburetor
|
|
Ignition:
|
CDI
|
|
Starting:
|
Kick
|
|
Max Power:
|
32 kW / 43 hp @ 6500 rpm (rear tyre: 28.8 kW / 38.6 hp @ 6900 rpm )
|
|
Max Torque:
|
49.5 Nm / 5.0 kgf-m / 36.5 lb-ft @ 5000 rpm
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Single down-tube full cradle
|
|
Rake:
|
30o
|
|
Trail:
|
124.5 mm / 4.9 in
|
|
Front Suspension:
|
39 mm Kayaba forks, air adjustable
|
|
Front Wheel Travel:
|
236 mm / 9.3 in
|
|
Rear Suspension:
|
Single Kayaba shock, adjustable spring preload
|
|
Rear Wheel Travel:
|
226 mm / 8.9 in
|
|
Front Brakes:
|
Single 280 mm disc, 2 piston caliper
|
|
Rear Brakes:
|
Drum
|
|
Front Tyre:
|
100/80 -21
|
|
Rear Tyre:
|
130/80 -17
|
|
Dimensions:
|
Length: 2215 mm / 87.2 in Width: 875 mm / 34.4 in Height: 1235 mm / 48.6 in
|
|
Wheelbase:
|
1465 mm / 57.7 in
|
|
Ground Clearance:
|
274 mm / 10.8 in
|
|
Seat Height:
|
925 mm / 36.4 in
|
|
Dry Weight:
|
136 kg / 300 lbs
|
|
Wet Weight:
|
150 kg / 331 lbs
|
|
Fuel Capacity:
|
21 Litres / 5.5 US gal / 4.6 Imp gal
|
|
Consumption average:
|
5.9 L/100km / 17.0 km/l / 40 US mpg / 48 Imp mpg
|
|
Braking 60 km/h - 0:
|
18.0 m / 59 ft
|
|
Braking 100 km/h - 0:
|
44.8 m / 147 ft
|
|
Standing ¼ Mile:
|
13.9 sec / 150.7 km/h / 93.6 mph
|
|
Top Speed:
|
163.9 km/h / 101.8 mph
|
