Technical specifications
|
| Model: |
SP 250 |
| Years: |
1982-84 |
|
Engine:
|
Four stroke, single cylinder, SOHC
|
|
Capacity:
|
249 cc / 15.2 cu in
|
|
Bore x Stroke:
|
72 x 61.2 mm
|
|
Compression Ratio:
|
8.9:1
|
|
Cooling System:
|
Air cooled
|
|
Induction:
|
Mikuni VM28SS carburetor
|
|
Ignition:
|
Transistorized
|
|
Starting:
|
Kick
|
|
Max Power:
|
12.7 kW / 17 hp @ 7800 rpm
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
Telescopic forks
|
|
Front Wheel Travel:
|
195 mm / 7.7 in
|
|
Rear Suspension:
|
Full floater
|
|
Rear Wheel Travel:
|
190 mm / 7.5 in
|
|
Front Brakes:
|
Drum
|
|
Rear Brakes:
|
Drum
|
|
Front Tyre:
|
3.00-21
|
|
Rear Tyre:
|
4.60 -17
|
|
Wheelbase:
|
1374 mm / 54.1 in
|
|
Seat Height:
|
826 mm / 32.5 in
|
|
Dry Weight:
|
119 kg / 262 lbs
|
|
Wet Weight:
|
124 kg / 273 lbs
|
|
Fuel Capacity:
|
9.5 Litres / 2.5 US gal / Imp 2.1 Imp gal
|
