Suzuki PE 250 (1977-78) technical specifications
Suzuki PE 250 is produced in 1977-78. Engine is Two stroke, single cylinder, piston and reed valve, displacement 246 cc / 15.0 cu in , produces power 21 kW / 28 hp @ 8000 rpm and 27.3 Nm / 2.78 kgf-m / 20.1 lb-ft @ 6500 rpm. Suzuki PE 250 weighs 111 kg / 245 lbs. Suzuki PE 250 has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | PE 250 |
| Years: | 1977-78 |
| Engine: | Two stroke, single cylinder, piston and reed valve |
| Capacity: | 246 cc / 15.0 cu in |
| Bore x Stroke: | 67 x 70 mm |
| Compression Ratio: | 7.1:1 |
| Cooling System: | Air cooled |
| Lubrication System: | Fuel/oil premix, 20:1 |
| Induction: | Mikuni VM36SS carburetor |
| Ignition: | Suzuki PEI |
| Spark Plug: | NGK B10EV, Nippon DENSO W31ES-G |
| Starting: | Kick |
| Max Power: | 21 kW / 28 hp @ 8000 rpm |
| Max Torque: | 27.3 Nm / 2.78 kgf-m / 20.1 lb-ft @ 6500 rpm |
| Clutch: | Wet, multiplate |
| Transmission: | 5 Speed |
| Final Drive: | Chain, DAIDO DID 520UB, 110 links |
| Primary Reduction: | 2.727 (60/22) |
| Final Reduction: | 4.000 (52/13) |
| Gear Ratios: | 1st 2.666 (32/12) / 2nd 1.750 (28/16) / 3rd 1.200 (24/20) / 4th 0.913 (21/23) / 5th 0.692 (18/26) |
| Front Suspension: | Telescopic phneumatic/coil spring, oil dampened |
| Rear Suspension: | Swingarm. gas/oil dampened spring, 3-way adjustable |
| Front Brakes: | Drum, internal expanding |
| Rear Brakes: | Drum, internal expanding |
| Front Tyre: | 3.00-21 4PR |
| Rear Tyre: | 4.50-18 4PR |
| Caster: | 60o |
| Trail: | 130 mm / 5.12 in |
| Steering Angle: | 50o (left & right) |
| Turning Radius: | 2.1 m / 6.9 ft |
| Dimensions: | Length: 2150 mm / 84.6in Width: 855 mm / 33.7 in Height: 1200 mm / 47.2 in |
| Wheelbase: | 1455 mm / 57.3 in |
| Ground Clearance: | 280 mm / 11.0 in |
| Dry-Weight: | 111 kg / 245 lbs |
| Transmission Oil Capacity: | 0.8 Litres / 0.85 US qt / 0.7 Imp qt |
| Fuel Capacity: | 10.6 Litres / 2.8 US gal / 2.3 Imp gal |
| Review: | Motorcycle-USA |
