Suzuki GSX-R125 (2017-18) technical specifications

Suzuki GSX-R125 is produced in 2017-18. Engine is Four stroke, single cylinder, DOHC, 4-valve, displacement 124.4 cc / 7.6 cu in Suzuki GSX-R125 has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	GSX-R125
Years:	2017-18
Engine:	Four stroke, single cylinder, DOHC, 4-valve
Capacity:	124.4 cc / 7.6 cu in
Bore x Stroke:	62 x 41.2 mm
Cooling System:	Liquid cooled
Lubrication System:	Wet sump
Induction:	Electronic fuel injection
Ignition:	Electronic
Starting:	Electric
Transmission:	6-Speed, constant mesh
Final Drive:	Chain
Front Suspension:	Telescopic fork, oil damped
Rear Suspension:	Link type monoshock, coil spring, oil damped
Front Brakes:	Single disc
Rear Brakes:	Single disc
Front Wheel:	Alloy, 10-spoke
Rear Wheel:	Alloy, 10-spoke
Front Tyre:	90/80-17 M/C, tubeless
Rear Tyre:	130/70-17 M/C, tubeless
Rake:	25.5o
Trail:	93.3 mm / 3.7 in
Dimensions:	Length: 1975 mm / 77.8 in Width: 670 mm / 26.3 in Height: 1070 mm / 42.1 in
Wheelbase:	1300 mm / 51.2 in
Ground Clearance:	150 mm / 5.9 in
Seat Height:	785 mm / 30.9 in
Fuel Capacity:	11 L / 2.9 US gal / 2.4 Imp gal
