Suzuki GSX-R 750 WV SRAD (1997) technical specifications
Suzuki GSX-R 750 WV SRAD is produced in 1997. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 749 c / 45.7 cub. in. , produces power 93.3 kW / 128 hp @ 12000 rpm and 80.5 Nm / 8.2 kgf-m / 59.3 ft-lb @ 1000 rpm. Suzuki GSX-R 750 WV SRAD top speed is 269.6 km/h / 167.5 mph. Suzuki GSX-R 750 WV SRAD weighs 179 kg / 394.6 lbs. Suzuki GSX-R 750 WV SRAD has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | GSX-R 750 WV SRAD |
| Years: | 1997 |
| Engine: | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder. |
| Capacity: | 749 c / 45.7 cub. in. |
| Bore x Stroke: | 72 x 46 mm |
| Compression Ratio: | 11.8:1 |
| Cooling System: | Liquid cooled |
| Engine Oil: | Synthetic,10W/40 |
| Exhaust System: | 4-into-2-into-1 Stainless-steel exhaust |
| Lubrication: | Wet sump |
| Induction: | 4 x 39 mm BDSR carburetors |
| Ignition: | Computer controlled electronic ignition |
| Spark Plug: | NGK, CR9E |
| Battery: | 8 Amp/hour |
| Starting: | Electric |
| Max Power: | 93.3 kW / 128 hp @ 12000 rpm |
| Max Power Rear Tyre: | 89.3 kW / 119 hp @ 10500 rpm |
| Max Torque: | 80.5 Nm / 8.2 kgf-m / 59.3 ft-lb @ 1000 rpm |
| Clutch: | Cable operated, wet multiple, coil spring |
| Transmission: | 6 Speed, constant mesh |
| Final Drive: | #530 Chain, O-ring sealed, 108 links |
| Gear Ratios: | 1st 2.87 / 2nd 2.06 / 3rd 1.65 / 4th 1.43 / 5th 1.26 / 6th 1.12:1 |
| Frame: | Conventional twin-beam aluminium construction |
| Front Suspension: | 43 mm Inverted telescopic forks, compression, rebound and preload adjustable. |
| Rear Suspension: | Rising rate monoshock, compression, rebound and preload adjustable. |
| Front Brakes: | 2 x 310 mm discs, 6 piston calipers |
| Rear Brakes: | Single 220 mm disc, 2 piston caliper |
| Wheels: | Alloy, 3 spoke |
| Front Tyre: | 120/70 ZR17 |
| Rear Tyre: | 190/50 ZR17 |
| Rake: | 24° |
| Dimensions: | Length 2055 mm / 80.9 in. Width 720 mm / 28.3 in. Height 1135 mm / 44.7 in. |
| Wheelbase: | 1400 mm / 55.1 in. |
| Seat Height: | 830 mm / 32.7 in. |
| Ground Clearance: | 130 mm / 5.1 in |
| Dry Weight: | 179 kg / 394.6 lbs |
| Wet Weight: | 194 kg / 427.7 lbs. |
| Fuel Capacity: | 18 Litres / 4.8 US gal / 3.6 Imp gal |
| Average Consumption: | 6.3 L/100 km / 16.0 km/l / 37.6 US mpg / 44.8 Imp mpg |
| Braking 60 km/h - 0 / 37 mph - 0: | 12.7 m / 41.6 ft |
| Braking 100km/h - 0 / 60 mph - 0: | 37.3 m / 122.4 ft |
| Standing ¼ mile: | 10.6 sec / 216 km/h / 134 mph |
| Standing 0 - 60 km/h / 37 mph: | 3.4 sec |
| Top Speed: | 269.6 km/h / 167.5 mph |
| Road Test: | Motosprint 1996 Superbike Group Test |
