Suzuki GSX-R 1000 Phantom (2006) technical specifications
Suzuki GSX-R 1000 Phantom is produced in 2006. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC, displacement 998.6 cc / 60.9 cub. in , produces power 131 kW / 178 hp @ 11000rpm and 118 Nm / 12 kgf-m / 87 ft -lb @ 8500rpm. Suzuki GSX-R 1000 Phantom top speed is 292.9 km/h / 181.9 mph. Suzuki GSX-R 1000 Phantom weighs 166 kg / 366 lbs. Suzuki GSX-R 1000 Phantom has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | GSX-R 1000 Phantom |
| Years: | 2006 |
| Production: | 200 Units |
| Engine: | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC |
| Capacity: | 998.6 cc / 60.9 cub. in |
| Bore x Stroke: | 74.3 x 59 mm |
| Compression Ratio: | 12.5:1 |
| Cooling System: | Liquid cooled |
| Lubrication: | Wet sump |
| Engine Oil: | Synthetic, 10W/40 |
| Exhaust: | 4 into 1 into 2, Stainless steel |
| Induction: | Electronic Fuel Injection with four 44mm throttle bodies |
| Ignition: | Electronic ignition, Transistorized |
| Starting: | Electric |
| Spark Plug: | NGK, CR9EIA-9 |
| Clutch: | Cable-operated multiplate wet clutch with back torque limiter |
| Max Power: | 131 kW / 178 hp @ 11000rpm |
| Max Torque: | 118 Nm / 12 kgf-m / 87 ft -lb @ 8500rpm |
| Transmission: | 6 Speed, constant mesh |
| Final Drive: | #530 chain |
| Gear Ratio: | 1st 2.562 / 2nd 2.052 / 3rd 1.714 / 4th 1.500 / 5th 1.360 / 6th 1.269:1 |
| Frame: | Aluminium, twin spar |
| Rake: | 23.75° |
| Trail: | 96 mm / 3.8 in. |
| Front Suspension: | 43mm Kayaba inverted cartridge forks with diamond-like coating adjustable for preload, compression and rebound damping |
| Front Wheel Travel: | 125mm / 4.9 in. |
| Rear Suspension: | Kayaba monoshock adjustable for ride height, preload, compression and rebound damping |
| Rear Wheel Travel: | 130 mm / 5.1 in. |
| Front Brakes: | 2 x 310 mm discs, 4 piston caliper |
| Rear Brakes: | Single 220 mm disc, 2 caliper |
| Wheels: | Cast aluminium, 3 spoke |
| Front Tyre: | 120/70 ZR17 |
| Rear Tyre: | 190/50 ZR17 |
| Wheelbase: | 1405 mm / 55.3 in. |
| Dimensions: | Length 2030 mm / 79.9 in Width 710 mm / 28 in Height 1130 mm / 44.5 in |
| Seat Height: | 810 mm / 31.9 in. |
| Ground clearance: | 125 mm / 4.9 in. |
| Dry Weight: | 166 kg / 366 lbs |
| Fuel Capacity: | 18 Litres / 4.8 US gal / 4.0 Imp gal |
| Average Fuel Consumption: | 6.9 l/100 km / 14.5 km/l / 34 US mpg / 41 Impmpg |
| Average Tank Range: | 195 km / 121 miles |
| Standing 0 - 160 km/h / 100 mph: | 5.2 sec. |
| Standing 0 - 100 km/h / 62 mph: | 2.8 sec. |
| Standing 1/4 mile: | 10.1 sec / 232.2 km/h / 144.3 mph |
| Top Speed: | 292.9 km/h / 181.9 mph |
