Suzuki GSX 750F Katana (2006-07) technical specifications
Suzuki GSX 750F Katana is produced in 2006-07. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 748 cc / 45.6 cu.in , produces power 69 kW / 92 hp @ 10500 rpm and 66 Nm / 6.73 kgf-m / 47.9 lb-ft @ 8500 rpm. Suzuki GSX 750F Katana top speed is 230 km/h / 143 mph. Suzuki GSX 750F Katana weighs 211 kg / 465 lbs. Suzuki GSX 750F Katana has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | GSX 750F Katana |
| Years: | 2006-07 |
| Engine: | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder. |
| Capacity: | 748 cc / 45.6 cu.in |
| Bore x Stroke: | 73 x 44.7 mm |
| Cooling System: | Air/oil cooled |
| Compression Ratio: | 10.9:1 |
| Lubrication: | Wet sump |
| Induction: | 4 x 36mm Mikuni BST36SS carburators |
| Ignition: | Electronic ignition |
| Spark Plug: | NGK JR9C |
| Starting: | Electric |
| Max Power: | 69 kW / 92 hp @ 10500 rpm |
| Max Torque: | 66 Nm / 6.73 kgf-m / 47.9 lb-ft @ 8500 rpm |
| Clutch: | Wet, multiple discs, cable operated |
| Transmission: | 6 Speed, constant mesh |
| Final Drive: | Chain, 118 Links |
| Final Reduction Ratio: | 3.133 |
| Gear Ratio: | 1st: 3.083 / 2nd: 20.62 / 3rd: 1.647 / 4th: 1.400 / 5th: 1.227 / 6th: 1.095 |
| Frame: | Double-cradle steel pipe |
| Front Suspension: | 41mm Telescopic fork, coil spring, oil damped, rebound damping adjustable, 3-way adjustable |
| Front Wheel Travel: | 125 mm / 4.9 in |
| Rear Suspension: | Link type, gas/coil spring, gas/oil damped, spring pre-load fully adjustable, compression damping force fully adjustable, rebound damping force 4-way adjustable |
| Rear Wheel Travel: | 136 mm / 5.4 in |
| Front Brakes: | 2 x 290 mm Discs, 2 piston calipers |
| Rear Brakes: | Single 250 mm disc, 2 piston caliper |
| Front Tyre: | 120/80-ZR17 |
| Rear Tyre: | 150/70-ZR17 |
| Caster: | 65° |
| Steering Angle: | 32° |
| Trail: | 101 mm /4.0 in |
| Dimensions: | Length 2135 mm / 84.1 in Width 750 mm / 29.5 in Height 1190 mm / 46.9 in |
| Wheelbase: | 1465 mm / 57.7 in |
| Seat Height: | 790 mm / 31.1 in |
| Ground Clearance: | 120 mm / 4.7 in |
| Dry Weight: | 211 kg / 465 lbs |
| Wet Weight: | 227 kg / 500 lbs |
| Fuel Capacity: | 20 Litres / 5.2 US gal / 4.4 Imp gal |
| Reserve: | 5 Litres / 5.3 US qt / 4.4 Imp qt |
| Consumption Average: | 5.3 L/100 km / 18.7 km/l / 44.1 US mpg / 53 Imp mpg |
| Standing ¼ Mile: | 11.5 sec |
| Top Speed: | 230 km/h / 143 mph |
