Suzuki GSX 400F Katana (1982) technical specifications
Suzuki GSX 400F Katana is produced in 1982. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 398 cc / 24.3 cu in , produces power 30.8 kW / 41.3 hp @ 10500 rpm and 30.2 Nm / 3.1 kgf-m / 22.3 lb-ft @ 8500 rpm. Suzuki GSX 400F Katana top speed is 170 km/h / 106 mph. Suzuki GSX 400F Katana weighs 179 kg / 395 lbs. Suzuki GSX 400F Katana has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | GSX 400F Katana |
| Years: | 1982 |
| Engine: | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder. |
| Capacity: | 398 cc / 24.3 cu in |
| Bore x Stroke: | 53 x 45.2 mm |
| Compression Ratio: | 10.2:1 |
| Cooling System: | Air cooled |
| Lubrication System: | Wet sump |
| Induction: | 4 x Mikuni BS26SS carburetors |
| Ignition: | Fully transistorised |
| Starting: | Electric |
| Battery: | 12V, 12Ah |
| Spark Plug: | NGK D8EA, NIPPON DENSO X24ES-U |
| Max Power: | 30.8 kW / 41.3 hp @ 10500 rpm |
| Max Torque: | 30.2 Nm / 3.1 kgf-m / 22.3 lb-ft @ 8500 rpm |
| Clutch: | Wet, multiplate |
| Transmission: | 6 Speed |
| Final Drive: | Chain, DAIDO DID50UB, 104 links |
| Primary Reduction: | 2.300 (92/40) |
| Final Reduction: | 2.866 (43/15) |
| Gear Ratios: | 1st 3.166 (38/12) / 2nd 2.125 (34/16) / 3rd 1.631 (31/19) / 4th 1.333 (28/21) / 5th 1.173 (27/23) / 6th 1.083 (26/24) |
| Front Suspension: | Telescopic fork, oil dampened |
| Front Wheel Travel: | 150 mm / 5.9 in |
| Rear Suspension: | Swingarm, dual shocks, oil dampened, spring 5-way adjustable |
| Rear Wheel Travel: | 107 mm / 4.2 in |
| Front Brakes: | 2 x Discs |
| Rear Brakes: | Single disc |
| Front Tyre: | 3.25-S19 4PR |
| Rear Tyre: | 3.75-S18 4PR |
| Steering Angle: | 42° (left and right) |
| Caster: | 63° |
| Trail: | 100 mm / 3.9 in |
| Dimensions: | Length: 2105 mm / 82.9 in Width: 750 mm / 29.5 in Height: 1135 mm / 44.7 in |
| Wheelbase: | 1415 mm / 55.7 in |
| Ground Clearance: | 165 mm / 6.5 in |
| Seat Height: | 780 mm / 30.7 in |
| Turning Radius: | 2.3 m / 7.5 ft |
| Dry Weight: | 179 kg / 395 lbs |
| Wet Weight: | 197 kg / 434 lbs |
| Fuel Capacity: | 15 Litres / 4.0 US gal / 3.3 Imp gal |
| Fuel Reserve: | 3.5 Litres / 3.7 US qt / 3.1 Imp qt |
| Oil Capacity: | 2.0 Litres / 2.1 US qt / 1.8 Imp qt |
| Top Speed: | 170 km/h / 106 mph |
| Standing 0 - 100 km/h: | 6.3 sec |
