Technical specifications
|
| Model: |
GSX 1300R Hayabusa |
| Years: |
2007 |
|
Engine:
|
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
|
|
Capacity:
|
1298 cc / 79.2 u in
|
|
Bore x Stroke:
|
81 x 63 mm
|
|
Compression Ratio:
|
11.0:1
|
|
Cooling System:
|
Liquid cooled
|
|
Lubrication:
|
Wet sump
|
|
Engine Oil:
|
10W/40
|
|
Induction:
|
Mikuni Denso Fuel Injection
|
|
Ignition:
|
Electronic
|
|
Spark Plug:
|
NGK, CR9E
|
|
Starting:
|
Electric
|
|
Max Power:
|
127.6 kW / 175 hp @ 9800 rpm
|
|
Max Torque:
|
138 Nm / 14.07 kg-m / 102 lb-ft @ 7000 rpm
|
|
Clutch:
|
Wet, multiple discs, hydraulic operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
#530 chain
|
|
Frame:
|
Twin-spar steel
|
|
Front Suspension:
|
Inverted telescopic, coil spring, fully adjustable spring preload, rebound and compression damping
|
|
Front Wheel Travel:
|
120 mm / 4.7 in
|
|
Rear Suspension:
|
Link-type, gas/oil damped, fully adjustable spring preload, compression damping, and rebound damping
|
|
Rear Wheel Travel:
|
140 mm / 5.5 in
|
|
Front Brakes:
|
2 x 320mm Discs, 6 piston calipers
|
|
Rear Brakes:
|
Single 240mm disc, 2 piston caliper
|
|
Front Tyre:
|
120/70 ZR17
|
|
Rear Tyre:
|
190/50 ZR17
|
|
Rake:
|
24.2°
|
|
Trail:
|
98 mm / 3.8 in
|
|
Dimensions:
|
Length 2140 mm / 84.3 in Width 740 mm / 29.1in Height 1155 mm / 45.5 in
|
|
Wheelbase:
|
1480 mm / 58.3in
|
|
Seat Height:
|
805 mm / 31.7 in
|
|
Dry Weight:
|
221.5 kg / 488.3 lbs
|
|
Wet Weight:
|
249 kg / 549 lbs
|
|
Fuel Capacity:
|
21 Litres / 5.5 US gal / 4.6 Imp gal
|
