Technical specifications
|
| Model: |
GS 850G |
| Years: |
1983-84 |
|
Engine:
|
Four stroke, transverse four cylinders, DOHC, 2 valve per cylinder.
|
|
Capacity:
|
843 cc / 51.4 cu in
|
|
Bore x Stroke:
|
69 х 56.4mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
8.8:1
|
|
Induction:
|
4 x mm Mikuni carburetors
|
|
Ignition:
|
Transistorized
|
|
Starting:
|
Electric & kick
|
|
Max Power:
|
57.1 kW / 77.6 hp @ 9.000 rpm
|
|
Max Torque:
|
65 Nm / 6.6 kgf-m 47.9 lb-ft @ 7.500 rpm
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Shaft
|
|
Front Suspension:
|
Telescopic forks, 3-way adjustable spring preload
|
|
Rear Suspension:
|
Dual shocks, 2-way preload and 4-way damping adjustments
|
|
Front Brakes:
|
2 x 275mm Discs
|
|
Rear Brakes:
|
Single 275mm disc
|
|
Front Tyre:
|
3.50-19
|
|
Rear Tyre:
|
4.50-17
|
|
Dimensions:
|
Length: 2235 mm / 88.0 in Width: 735 mm / 28.9 in Height: 1145 mm / 45.1 in
|
|
Seat Height:
|
785 mm / 30.9 in
|
|
Ground Clearance:
|
160 mm / 6.3 in
|
|
Wet Weight:
|
253 kg / 557 lbs
|
|
Fuel Capacity:
|
22 Litres / 5.8 US gal / 4.8 Imp gal
|
|
Consumption Average:
|
5.5 L/100 km / 18.3 km/l / 43 US mpg / 51.6 Imp mpg
|
|
Top Speed:
|
191 km/h / 119 mph
|
